一種變頻電路的研究
INVESTIGATION OF A FREQUENCY CONVERSION CIRCUIT
-
摘要: 我們研究了一種效率高、結構簡單可靠、頻率可調范圍寬的非線性電路。建立了在該電路中(交流和飽和狀態運用)以鐵氧體作為非線性電感的數學模型。從實驗著手,借助于計算機輔助分析,探討了該非線性電路的變頻特性、倍頻極限和功率輸出。最后把計算機的計算結果與實驗結果進行了比較。
-
關鍵詞:
Abstract: A nonlinear circuit is investigated, which is characterized by high effeciency, simple and reliable construction, and large tuning frequeney range. For the circuit operating in AC and saturation condition, a mathematical model of the ferrites as the nonlinear inductance element is built up. Along with the exp-erimental work done on the circuit, the frequency conversion characteristics of the nonlinear circuit, the limit of the frequency multiplication, and the power output are discussed by means of compute-aided analysis. Computed results by computer are compared with the experimental ones. -
戴光祖,非線性網絡變頻器,1979年電路和系統學會年會資料.[2]俞大光,電工基礎(中冊),第1版,人民教育出版社,1964年,第102頁.[4]C. W. Gear, IEEE Trans. on CT, CT-18(1971), 89. -
