時變級聯濾波器的兩種設計方法
TWO APPROACHES TO THE DESIGN OF TINE-VARYING CASCADED FILTERS
-
摘要: 本文針對雷達雜波抑制中常用的時變級聯濾波器,提出了兩種實用的設計方法。第一種方法通過時變級聯濾波器與時變非級聯濾波器的等效來設計時變級聯濾波器。該方法可以使時變級聯濾波器具有最佳雜波濾波器的效果。第二種方法通過對總的等效濾波器的設計來得到級聯濾波器第二級的權系數。分析表明,時變級聯濾波器第二級的頻率響應很難寫出,但可以通過總的等效頻率響應來體現。
-
關鍵詞:
- 時變?yōu)V波器; 雜波抑制; 雷達信號處理
Abstract: Two approaches to the design of the time-varying cascaded filters used in radar clutter rejection are presented. In the first approach, by fitting the cascaded filter to the noncascaded filter, the time-varying cascaded filter can be designed, which makes it possible that the time-varying cascaded filter behaves just like an optimum clutter filter. The second approach can be used to design the second-stage filter in a time-varying cascaded one by setting zeros in its equivalent overall frequency response. It has been shown that the frequency response of the second-stage filter in the time-varying cascaded filter is difficult to express, however, is convenient to be involved in the overall response. -
Hsiao J K. IEEE Trans. on AES, 1974, AES-10(5): 622-629.[2]Wu Huan, Zhang Shouhong, Bao Zheng. Adaptive Cascaded Clutter Canceler for Staggered PRF Radar. Proceedings of the 1991 CIE Internationai Conference on Radar. Beijing: 503-506. -
