基于多譜圖疊加閾值的抑制WVD交叉項的新方法
A New Method to Suppress Cross-Terms of WVD via Thresholding Superimposition of Multiple Spectrograms
-
摘要: 本文提出了一種抑制Wigner-Ville分布(WVD)交叉項的新方法。 首先對多幅具有不同時-頻分辨率的譜圖進行疊加, 然后對疊加結果進行閾值處理，確定WVD自項在時頻平面的支撐區域。 最后，用該區域的示性函數乘以WVD得到一個新的時頻分布。 不同于傳統的抑制交叉項的核函數方法, 該方法抑制交叉項的同時, 保持WVD了高時頻聚集性。 實驗結果表明, 該方法對由多個LFM信號構成的多分量信號和非線性調頻信號都非常有效。
-
關鍵詞:
- Wigner-Ville分布;譜圖;交叉項;自項;閾值處理
Abstract: In this paper, a new method is proposed to suppress the cross-terms of Wigner-Ville Distribution (WVD), which is based on thresholding the superimposition of multiple spectrograms. First, the spectrograms with different time-frequency resolutions are superimposed and then the superimposition is thresholded to localize the auto-term support region of the WVD. Secondly, the WVD is multiplied by the indication function of the region. In this way, a new Time-Frequency Distribution (TFD) is obtained. Unlike the traditional kernel function methods to suppress cross terms, our method not only reduces the interfering cross-terms but also preserves the superb time-frequency concentration of the WVD. The experimental results show that the method is very effective for both the multicomponent signals consisted of the LFMs and nonlinear frequency modulation chirp signals. -
Cohen L. Time-Frequency Analysis. Englewood Cliffs，NJ: Prentice Hall, 1995:136-148.[2]Jeong J, Williams W J. Kernel design for reduced interference distributions[J].IEEE Traps. on Signal Processing.1992, 40(2):402-412[3]Baraniuk R G, Jones D L. A signal-dependent time-frequency representation: Optimal kernel design[J].IEEE Traps. on Signal Processing.1993, 41(4):1589-1602[4]Baraniuk R G, Jones D L. A signal-dependent time-frequency representation: Fast algorithm for optimal kernel design[J].IEEb Traps. on Signal Processing.1994, 42(1):134-146[5]Jeong J-C, Williams W J. Mechanism of the cross-terms in spectrograms[J].IEEE Traps. on烤pal Processing.1992, 40(10):2608-2613[6]Mann S, Haykin S. The chirplet transform: Physical considerations[J].IEEE Traps. on Signal Processing.1995, 43(11):2745-2761[7]Bultan A. A four-parameter atomic decomposition of chirplets[J].IEEE Traps. on Signal Processing.1999, 47(3):731-745[8]Clasen T C, Mecklenbrauker W F. The aliasing problem in discrete-time Wigner distribution[J].IEEE Traps. on Acoust., Speech, and Signal Processing.1983, 31(6):1067-1072 -
