運動目標環境下的調頻步進信號目標抽取算法
Targets Redundancy Removed Algorithm for Modulated Frequency Stepped Pulse Radar Signal Echoed by Moving Target
-
摘要: 為了減少采樣損失，調頻步進信號的采樣率通常高于chirp子脈沖的帶寬。在這種過采樣冗余情況下，需要對IFFT合成高分辨結果進行目標抽取去冗余方能得到高分辨一維距離像。然而當目標運動時，目標抽取的結果會產生目標丟失或偽峰等現象。該文提出了一種基于幅度最強像偏移量的動目標抽取算法，該方法利用幅度最強像的偏移量修正各采樣點的目標抽取范圍，從而解決了速度估計誤差引起的速度-距離耦合對目標抽取算法的影響。計算機實驗結果驗證了理論分析的正確性。Abstract: To reduce the loss of sampling, higher sampling frequency than bandwidth of chirp must be adopted for Modulated Frequency Stepped Pulse(MFSP) radar signal, which will bring on over-sampling result of pulse compression for chirp. So the pick-up algorithm for the MFSP radar signal must be adopted to eliminate targets redundancy in order to obtain fine HRRP(High-Resolution Range Profile). However, because of inaccuracy of the velocity compensation method, the velocity error of the moving target will produce velocity-range coupling error, even bring the influence of losing target or producing spurious peaks on the HRRP. This paper proposes a targets redundancy removed algorithm based on the offset of the most powerful scatterer, which can solve the velocity-range coupling problem effectively by modifying the pick-up scopes of all sampled points. Finally, the processing results of both simulated data and real radar data validate the correctness of theoretical analysis.
-
