開縫矩形腔屏蔽特性的研究
Analysis on Shielding Effectiveness of Rectangular Cavity Perforated with a Single Slot
-
摘要: 該文計算了在矩形腔上開有單縫時，縫長變化對所激勵的屏蔽腔中最低模式的幅度和頻率特性的影響。同時，采用時域-頻域聯合分析的方法，對屏蔽腔內觀察點時域波形進行了分析，得到了不同頻率分量在時域上的變化特性，以及縫長變化對它們的影響。
-
關鍵詞:
- 屏蔽腔;開縫;屏蔽效應;時域-頻域聯合分析
Abstract: The shielding effectiveness of a rectangular enclosure perforated with a slot is analyzed and the influences of the slot length on the magnitude and frequency of the lowest mode stimulated by the slot are given. Joint time-frequency analysis is also applied to explore the time domain waveform of every frequency component at observation point. The influence of the slot length to the time domain characteristics of different resonant mode is also obtained. -
Li M, Drewniak J L, Radu S, et al.. An EMI estimate for shielding-enclosure evaluation[J].IEEE Trans. on Electromagn. Compat.2001, 43(3):295-303[2]王建國，屈華民，范如玉，等. 孔洞厚度對高功率微波脈沖耦合的影響. 強激光與粒子束，1994，6(2): 282-286.[3]Belokour I, LoVetri J, Kashyap S. Shielding effectiveness estimation of enclosures with apertures. IEEE Int. Symp. Electromagn. Compat., Washington. DC, USA: 2000, Piscataway, 2000: 855-860.[4]付繼偉，候朝楨，竇麗華. 電磁脈沖斜入射時對孔縫耦合效應的數值分析. 強激光與粒子束，2003，15(3): 249-252.[5]Li M, Nuebel J, Drewniak J L, et al.. EMI from cavity modes of shielding enclosures- FDTD modeling and measurements[J].IEEE Trans. on Electromagn. Compat.2000, 42(1):29-38[6]Audone B, Balma M. Shielding effectiveness of apertures in rectangular cavities[J].IEEE Trans. on Electromagn. Compat.1989, 31(1):102-106[7]Harrington R F, Mautz J R. Characteristic modes for aperture problems[J].IEEE Trans. on Microwave Theory Tech.1985, 33(6):500-505[8]Robinson M P, Benson T M, Christopouolos C, et al.. Analytical formulation for the shielding effectiveness of enclosures with apertures. IEEE Trans. Electromagn. Compat., 1998, 44(3): 240-247.[9]Johnk R T, Novotny D R, Archambeault B. Using joint time- frequency analysis to enhance time-domain numerical EMC[10]simulations. Interference Technology, 2003: 113-124. -
