非理想第二類電流傳送器及其應用
NONIDEAL SECOND-CLASS CURRENT CONVEYER AND ITS APPLICATION
-
摘要: 本文定義了一種非理想第二類電流傳送器(NCCII);給出了用跨導運算放大器(OTA)實現NCCII的電路;討論了用該電路實現的電容和電阻變換器。
-
關鍵詞:
- 電流傳送器; 跨導運算放大器; 電容變換器
Abstract: A nonideal second current conveyer (NCCII) is described. The circuit of NCCII constructed with operational transconductance amplifers (OTA) only is proposed. The current conveyer of this used as a circuit building block to realize capacitor and resistance converters is also reported. -
C. K. Smith, A. Sedra, IEEE Proc., 56(1968)8, 1368-1369.[2]B. Wilson, IEE Proc.-G, 137 (1990)2, 63-77. -
