介質環加載喇叭的理論分析
THEORETICAL ANALYSIS OF THE DIELECTRIC LOADED HORN
-
摘要: 本文對介質環加載邊界條件特征方程進行了求解。導出了介質環加載波導與光壁波導連接處的模轉換計算公式。并且根據這些公式計算了文獻[1]設計的介質環加載喇叭的輻射特性,計算結果非常接近實測結果。
-
關鍵詞:
Abstract: This paper gives a solution of the characteristic equations of the boundary conditions of the dielectric ring loaded horn. This leads to transformation formulas for the connecting boundary of the dielectric ring loaded waveguide and smooth walled waveguide. Using these formulas, the radiation characteristics of the dielectric ring loaded horn according to the design in reference [1] are found. The calculated values are very close to experimental results. -
楊世華,介質加載喇叭,新鄉天線會議錄,1977, 4,(待印).[2]Toshio satoh, IEEE Trans, On AP, AP-20 (1972), 199.[3]章日榮、劉順祥等,光壁波導與介質充填波導的模轉換,本所內部資料,1976.7.[4]章日榮,介質環加載波導與光壁波導模轉換的近似計算,本所內部資料,1978. 12.[5]章日榮、李鳳芝,復合式多模喇叭,電子學報,1978,第2期,第9頁. -
