蒸發波導中電磁波異常傳播特征研究及其應用
Study on Anomalous Propagation Characteristics of Electromagnetic Waves in Evaporation Duct Environments and its Application
-
摘要: 蒸發波導是海洋大氣環境中一種典型的異常大氣折射結構。它能夠部分地陷獲電磁波的傳播，從而改變電磁波的傳播特征。這種特性在雷達、通信、電子對抗等設備的使用方面具有廣泛的應用。該文主要利用電磁波傳播的拋物型數值方程和裂步傅里葉算法，通過仿真方法研究了蒸發波導環境下電磁波所具有的異常傳播特征，并利用2003年8月大連海域的雷達異常探測試驗作為應用實例，說明了蒸發波導對電磁波異常傳播以及對雷達異常性能的影響。
-
關鍵詞:
- 電磁波; 蒸發波導; 異常傳播特征;雷達;性能評估
Abstract: Evaporation duct is a kind of typical anomalous profile of atmospheric refractivity, it can partly trap electromagnetic waves, as a result, the propagation characteristics are changed, which may be applied in electronic equipments such as radar, communication and ECM, etc. The purpose of this article is to study on anomalous characteristics of electromagnetic waves in evaporation duct environment through simulation methods based on electromagnetic waves propagation parabolic numerical equation and split-step Fourier algorithm technology. The experimental data of radar abnormal detection in Dalian Sea Area in October of 2003 is analyzed as an example of application to validate the abnormal characteristics of the electromagnetic waves and the anomalous detection of radar influenced by evaporation ducts. -
Patterson W L.[J].et al.. Engineers refractive effect prediction system (EREPS)[R]. San Diego, CA: Naval Command, Control and Ocean Surveillance Center(NCCOSC), Naval Research and Development(NRaD) Technology Report.1994,2648:-[2]戴福山, 等. 海洋大氣近地層折射指數模式及其在蒸發波導分析上的應用[J]. 電波科學學報, 1998, 13(3): 280-286.[3]劉成國, 等. 我國對流層波導環境特性研究[J]. 西安電子科技大學學報(自然科學版), 2002, 29(1): 119-122.[4]姚展予, 等. 大氣波導特征分析及其對電磁波傳播的影響[J]. 氣象學報, 2000, 58(5): 605-616.[5]Barrios A E. A terrain parabolic equation model for propagation in the troposphere[J]. IEEE Trans. on AP, 1994, 42(1): 90-98.[6]Dockery G D. Modeling electromagnetic wave propagation in the troposphere using the parabolic equation[J]. IEEE Trans. on AP, 1988, 36 (10): 1464-1470.[7]丁鷺飛, 等. 雷達原理[M]. 西安：西安電子科技大學出版社, 1995, 第3章, 5章.[8]Blake L V. Radar range-performance analysis[M]. Norwood, MA: Artech. House, 1986, chap.1-3. -
