三相平衡式單可控硅充電電路的研究
THE INVESTIGATION OF A THREE-PHASE CHARGING CIRCUIT BALANCED WITH ONE THYRISTOR
-
摘要: 本文根據蓄電池充電的特點,提出了一種僅僅使用一只普通的可控硅輪流控制三相的平衡式充電電路,它克服了一般單相和三相可控硅充電電路的缺點,而又吸取了后兩種電路的優點。它以最簡單的方法實現在整個范圍內的三相處處同步調節,這就打破了在三相平衡電網中,要使三相達到平衡,必須用多只可控硅來同步調節,以實現輸出直流電壓調壓的傳統做法。這為可控硅充電設備的設計提出了一種既簡單、又經濟、且三相能平衡調節的可控硅實用新電路。
-
關鍵詞:
Abstract: Based on the specific requirements of battery charging, a three-phase balanced eharg-ing circuit controlled with one thyristor is proposed. This circuit is free from the defects existing in general single-or three-phase thyristor charging circuit but has the abvantages of the both. It is capable of achievement of three-phase synchronous re-gulation throughout the whole range by a simple way. Thus, it is different from the traditional method. there is no need to adopt multi-thyristor in three-phase balanced network to balance and synchronize the regulated D.C. output voltage. The purpose of this paper is to present a new practical circuit which is not only simple, economic, but also able to be three-phase balanced in voltage regulation, thus providing a good design of charging equiplent controlled with one thyristor. -
龔秋聲,洪都科技,1 (1980), 1.[2]牛景漢,電子科學技術,4(1979), 22.[3]江南造船廠,華東電氣傳動,3(1978), 35.[4]А.Н.Авров著,鄒立安譯,電子管振蕩器在電加熱中的應用,國防工業出版社,1956年,第48頁.[5]機床設計手冊編寫組編,機床設計手冊5,電力傳動及控制系統設計(上冊),機械工業出版社,1979年,第212-235頁. -
