高速集成電路中多導體漸變互連線傳輸特性的分析
ANALYSIS OF THE TRANSMISSION PROPERTIES OF TAPERED MULTICONDUCTOR INTERCONNECTING BUSES IN HIGH SPEED INTEGRATED CIRCUIT
-
摘要: 本文首先給出高速集成電路中多導體均勻互連線傳輸特性的分析方法和計算公式。再將漸變互連線近似為線寬略有變化的多節均勻線級聯,通過網絡理論,分析出漸變線的傳輸特性。計算結果與測量值吻合很好。
-
關鍵詞:
- 高速集成電路; 互連; 傳輸線; 網絡; 散射參數
Abstract: Analysis approach and formulas for the transmission properties of uniform multiconductor interconnecting buses in high s peed integrated circuits are presented in this article. And further, by using a network approach, a tapered bus system can be analysed as a set of cascaded uniform buses with slightly different strip widths. Obtained results are in good agreement with the experimental data. -
B. A. Rretch, et al., IEEE Trans. on MTT, MTT-35(1987)8, 710-718.[2]M. A. Mehalic, et al., IEEE Trans. on MTT, MTT-38(1990)11, 1559-1567.[3]E. Pettenpaul, et al, IEEE Trans. on MTT, MTT-36(1988)2, 294-304.[4]R. Faraji-Dana, et al., IEEE Trans. on MTT, MTT-38(1990)9, 1268-1277. -
