矩形波導中小導體異物的影響
THE EFFECT OF A SMALL CONDUCTING FOREIGN BODYIN THE WAVEGUIDE
-
摘要: 本文利用矩形諧振腔中的教擾公式結合準靜態近似,導出了矩形波導中小導體異物的等效串聯電抗和并聯電納。求出了反射系數,傳輸相移及功率容量降低的表示式.這種表示式在試驗中表明是適合的。
-
關鍵詞:
- 波導系統; 微擾; 準靜態近似; 功率容量
Abstract: The equivalent series reactance and parallel susceptance of a small conclucring foreign body in the rectangular waveguides are derived by using perturbational formula in the rectangular cavity and combining with quasi-static approximation. The expressions of its reflection coefficient, transmission phase displacement and power carrying capacity reduction are also given. The expressions are shown that is satisfactory in experiment. -
J. Hinken, IEEE Trans. on MTT, MTT-28(1980)7, 711-744.[2]林為干,成都電訊工程學院學報,29(1983)1,12-23;中國科學,A集,27(1984)2, 184-195.[3]王典成,電磁場理論與微波技術,科學出版社,1986年.[4]哈林登著,孟侃譯,正弦電磁場,上?？茖W(xué)出版社,1964年.[5]А.Л.Фельдштейн,Правочник по Элементам Волноводной Техники Москва,(1963). -
