一般線性網絡的混合分析法
THE MIXED ANALYSIS METHOD OF GENERAL LINEAR NETWORKS
-
摘要: 本文應用網絡圖論提出了圈-離集混合基矩陣的概念、混合基中基爾霍夫定律的矩陣表示和一般線性網絡的混合基方程,進而建立了一般線性網絡的圈電流-離集電壓混合分析法。這個方法把文獻[4]關于無源和無互感網絡的混合分析法推廣到包括有源和有互感網絡在內的一般的線性時不變集總參數網絡的情況。
-
關鍵詞:
Abstract: In this paper, by applying the network graph theory, the concept of cycle-seg mixed basis matrix, the matrix representation of Kirchhoff s law in the mixed basis and the mixed basis equations of general linear networks are presented. Then the cycle current-seg voltage mixed analysis method of general linear networks is established. By this way, the mixed analysis method for passive networks without mutual inductances in referenee [4] is extended to one for active networks with mutual inductances. -
W. K. Chen, Applied Graph Theory, North-Holland Publishing Company, Amsterdam, London,1971, p. 36-76.[4]王春華,圖論與網絡拓?fù)浞治?計算機輔助設計,科學技術文獻出版社重慶分社,1979年,第1-15頁.[5]張惠廉、莊鎮泉,電子線路的計算機輔助設計,上冊,人民教育出版社,1979年,第86-121頁.[6]邱關源,網絡圖論簡介,人民教育出版社,1978.[7]Claude Berge, Graphs and Hypergraphs, North-Fholland Publishing Company, Amsterdam, London,1973, p. 3-17. -
