對稱雙層FSS的傳輸特性分析
ANALYSIS OF TRANSMISSION PROPERTIES OF A SYMMETRIC DOUBLE-LAYER FSS
-
摘要: 應用模匹配方法,研究了關于中心層面對稱的雙層頻率選擇表面(FSS)的傳輸特性。討論了各介質層厚度改變對頻率選擇表面頻響特性的影響,指出通過修正雙層FSS的有關介質參數,可以有效地改善傳輸帶寬的穩定性并縮小傳輸曲線諧振區的深溝。Abstract: A symmetric double-layer frequency selective surface is studied by adopting the symmetric and anti-symmetric excitation method. Transmission properties of the structure are discussed for different dielectric parameters of the structure. It is shown that the frequency response of the structure can be great by improved by choosing suitable dielectric parameters of the covering and coating layers.
-
Mittra R. Chan C H, Cwik T. Techniques for analyzing frequency selective surfaces--A review Proc. IEEE, 1988,76(12): 1593-1615.[2]Luebbers R J, Munk B A. Some effects of dielectric loading one periodic slot arrays. IEEE Trans on Antennas Propagat, 1978, AP-26(4): 536-542.[3]Chan C H, Mittra R. On the analysis of frequency selective surfaces using subdomain basis functions. IEEE Trans. on Antennas Propagat. 1990, AP-38(1): 40-50.[4]Parker E A, Vardaxoglou J C. Influence of single and multiple-layer dielectric substrates on the band spacing available from a concentric ring frequency selective surface[J].International Journal of Electronics.1986, 61(3):291-297[5]Huang J, Wu T K, Lee S W. Tri-band frequency selective surfaces with circular ring elements.IEEE Trans. on Antennas Propagat. 1994, AP-42(2): 166-175.[6]Hall R C, Mittra R, Mitzner K M. Analysis of multilayered periodic structure using generalized scattering matrix theory. IEEE Trans. on Antennas Propagat, 1988, AP-36(4): 511-517.[7]Pons R, Pozar D M. A frequency selective surfaces using aperture-coupled microstrip patches IEEE Trans. on Antennas Propagat. 1991, AP-39(12): 1763-1769. -
