FDTD結合最小二乘擬合法分析PBG濾波結構
Analysis of Microstrip PBG Filter Structures Using FDTD with Least Square Fitting Method
-
摘要: 為了能應用FDTD方法快速有效地分析各種PBG濾波結構電磁特性，該文應用FDTD結合最小二乘擬合法對兩類新型PBG濾波結構進行了具體分析，給出了FDTD結合最小二乘擬合法計算的最小迭代步數和如何選出諧振段去除振蕩原則，最后通過數值仿真結果，表明該方法能有效減少FDTD的迭代步數，節省計算時間，特別適用于大周期和復雜的PBG濾波結構分析。
-
關鍵詞:
- FDTD;最小二乘擬合法;PBG濾波結構
Abstract: In this paper, the FDTD with least square fitting method is used to calculate the S parameters of PBG filter structures, Furthermore, the least square fitting method is employed combined with FDTD to reduce the iterative steps. To show the accuracy of the method, a simulated result is given in the latter part of the paper and various comparisons are made for such a demonstration. -
Yablonovitch. E. Inhibited spontaneous emissionin solid-state physics and electronics[J].Phys. Rev. Lett.1987,58(20):2059-[2]Rumsey I, Piket-May M, Kelly P K. Photonic band gap structures used as filters in microstrip circuits. IEEE Microwave and Guided Wave Lett. , 1998，8(10): 336338. .[3]Zee Iluz, Reuven Shavit, Reuven Bauer. Microstrip antenna phased array with electromagnetic bandgap substrate. IEEE Trans. on Microwave Theory and Techniques, 2004 52(6): 1446.1453.[4]Anaya M，Marcotegui J A，Lopetegi T，G.Laso M A, Sorolla. M. Analysis of new periodic structures in microstrip by FDTD. European Congress on Computational Methods in Applied Sciences and Engineering, Barcelona，Spain, September 2000: 11.14.[5]宋健, 張玉, 梁昌洪. 共形FDTD分析圓形光子帶隙微帶結構. 西安電子科技大學學報，2004，31(5): 678681. .[6]Nesic D, Nesic A. Band stop microstrip PBG filter with sinusoidal variation of the characteristic impedance and without etching in the ground plane[J].Microwave and Optical Technology Letters.2001,29(6):418-[7]閆敦豹, 袁乃昌, 付云起. 基于FDTD的波導介質層PBG結構的研究. 電子與信息學報，2004，26(1): 118123. -
