使用單位增益緩沖器構成的抗寄生SC跨導
PARASITIC TOLERANT DIFFERENTIAL SC TRANSCONDUCTANCE USING UNITY GAIN BUFFERS
-
摘要: 用單位增益緩沖器構成的開關電容濾波器(SCF),若能消除寄生電容引起的阻性寄生,則可用于高頻設計,總寄生靈敏度會因此大大降低。本文在此基礎上提出一種新的抗寄生開關電容(SC)跨導元件電路差分跨導元件,并用它構成了適用于高頻的SC浮地電感和積分器。最后用它實現了一個三階橢圓函數低通濾波器,并經計算機模擬和實驗驗證,證明了該方案的正確性。
-
關鍵詞:
- 單位增益緩沖器; 開關電容濾波器; 差分跨導元件; 低通濾波器
Abstract: The unity gain buffer will be good for designing high frequency SCF if its resistive effect can be eliminated and then the overall parasitic sensitivity will be greatly lowered. Based on this concept, a new parasitic tolerant SC differential transconductance element (DTE) is proposed. SC floating inductor and integrator applicable to high frequency are formed by using the DTE. The computer simulation and experiment on a 3-order elliptic LP filter show the correctness of the concept. -
K. Nagaraj, J. Vlach, IEEE Trans on CAS, CAS-35(1988)1, 35-42.[2]A. De La Plaza, IEEE J. of SC, SC-21(1986)6, 470-477.[3]A. Fettweis, AEU, 33(-1979)1, 13-19.[4]S. C. Fan, et al., Switched-Capacitor Fitters Using Unity Gain Buffers, Proc. ISCAS'80, Houston, (1980), pp. 334-337.[5]T. R. Wiswarathan, et al., IEEE Trans on CAS., CAS-27(1980)6, 502-508.[6]J. A. Nossek, G. C. Temes, IEEE Trans on CAS., CAS-27(1980)6, 481-491.[7]H. J. Orchard, G. C. Temes, Spectral Analysis of Switched-Capacitor Filters Designed Using Bilinear Z-Transform, Conf. Rec. of 21th AsiIomar Conf, on Cirsuits Syst.and Computers, (1987), pp. 674-678.[8]M. S. Lee, C. Chang, IEEE Trans. on CAS, CAS-27(1980)6, 475-480. -
