孿生TR開關管相位特性的研究
INVESTIGATION OF THE PHASE PERFORMANCE IN DUAL-TR TUBE
-
摘要: 本文從實驗上研究了平衡天線開關中孿生TR管的兩單管間的相位差對開關接收損耗和接收駐波比的影響。結果表明,當兩單管間的相位差大于30時,則接收損耗將大于0.5dB,接收駐波比也相應增大。文中還將實驗結果和理論計算作了比較。 本文還研究了由三級插入式放電管組成的孿生TR管中各級管子的相位與整管相位的關系;結果表明,這個關系近似地符合相位疊加原則。
-
關鍵詞:
Abstract: In this paper, the influences of phase difference between two single tubes of dual-TR tube on receiving lose and receiving VSWR in balaneed duplexer are investigated exper-imentally. The experimental results show, if the phase differenee is greater than 30 degrees, then the receiving loss will exceed 0.5 dB and the VSWB will increase correspon-dingly. It shows that the experimental results are comparable with the theoretical calculations.The relation between the phase of individual stage of the three-stage plug-in discharge tube and the phase of the dual-TR tube is investigated. The experimental results indicates that this relation approximately obeys the superposition principle. -
柯錦松等,電子學通訊,1(1979),129.[5]L.W.Roberts et al.著, 唐良芬譯, 國外電子器件,1964年,第4期,第30頁.[7]C.W.Jones, IRE Trans. on MTT, MTT-5 (1957), 4. -
