一種性能優良的和頻上變頻器
HIGH-PERFORMANCE SUM-FREQUENCY UPCONVERTER
-
摘要: 本文介紹一種結構新穎、性能優良的8mm波段和頻上變頻器。變頻器的變頻損耗為2.9dB;1dB壓縮點輸出功率1.34mW;和頻信號小于1mW范圍內,變頻器具有極好的線性;和頻信號比雜散組合頻率譜線強30dB以上;各端口隔離度均大于40dB。
-
關鍵詞:
- 上變頻器; 雙脊波導; 變?nèi)莨?/a>
Abstract: A new 8 mm high-performance sum-frequency upconverter is described. Ttsconversion loss is 2.9 dB; its output power is 1.34mW at 1 dB compression point. As the power of sum-frequency signal below 1mW, the upconverter shows a very good linearity. Sum-frequency signal is 30 dB higher than stray spectrum. The isolation of each port is over 40 dB. -
鄧紹范等,八毫米波段和頻上變頻器研究報告,哈爾濱工業大學,哈爾濱,1987年.[2]Shizuo Mizushina et al., IEEE Trans. on MTT. MTT-25(1977)12, 1131-1134.[3]L.T. Yuan, IEEE Trans. on MTT, MTT-25(1977)12, 1048-1054.[4]徐德忠等,八毫米波段和頻上變頻器測試報告,航空航天部弟二研究院計量研究所,北京,1987年. -
