一種低靜態電流、高穩定性的LDO線性穩壓器

陳東坡; 何樂年; 嚴曉浪

一種低靜態電流、高穩定性的LDO線性穩壓器

計量
- 文章訪問數: 3425
- HTML全文瀏覽量: 169
- PDF下載量: 2710
- 被引次數: 0
出版歷程
- 收稿日期: 2005-11-28
- 修回日期: 2006-04-14
- 刊出日期: 2006-08-19

A Low-dropout Regulator with Low Quiescent Current and High Stability

摘要

摘要: 該文提出了一種低靜態電流、高穩定性低壓差(LDO)線性穩壓器。LDO中的電流偏置電路產生30nA的低溫度漂移偏置電流，可使LDO的靜態工作電流降低到4A。另外，通過設計一種新型的動態Miller頻率補償結構使得電路的穩定性與輸出電流無關，達到了高穩定性的設計要求。芯片設計基于CSMC公司的0.5m CMOS混合信號模型，并通過了流片驗證。測試結果表明，該穩壓器的線性調整和負載調整的典型值分別為2mV和14mV；輸出的最大電流為300mA；其輸出壓差在150mA輸出電流，3.3V輸出電壓下為170mV；輸出噪聲在頻率從22Hz到80kHz間為150VRMS。
- 低壓差線性穩壓器;靜態電流;穩定性;線性和負載調整
Abstract: An unconditionally stable low-dropout regulator and low quiescent current is presented. The Low DropOut ( LDO) based on a high precision CMOS current reference, which is comprised of subthreshold transistors and has small temperature coefficient, provides a low quiescent current of approximately 4A. Furthermore, by utilizing the design method of active Miller frequency compensation, the proposed LDOs stability is independent of the load or the Equivalent Series Resistance (ESR) of the off-chip capacitor. The chip design is based on 0.5#61549;m CMOS mixed-signal process of CSMC. The simulation and experimental results show that the line and load regulations are only 2mV and 14mV, respectively. The dropout voltage is only 170mV at 150mA output current when output voltage is 3.3V. The output noise is 150VRMS when frequency range is from 22Hz to 80 kHz.

HTML全文

參考文獻(1)

Leung K N, Mok P K T. A capacitor-free CMOS low-dropout regulator with damping-factor-control frequency compensation[J].IEEE Journal of Solid-State Circuits.2003, 38(10):1691-1720[2]Leung K N, Mok P K T, Ki W H. A novel frequency compensation technique for low-voltage low-dropout regulator. IEEE International Symposium on Circuits and Systems, Florida: Orlando, May 1999, Vol.5: 102-105.[3]Kwok K C, Mok P K T. Pole-zero tracking frequency compensation for low dropout regulator. IEEE International Symposium on Circuits and Systems, Arizona: Scottsdale, May 2002, vol. 4: 735-738.[4]Rincon-Mora G A, Allen P A. A low-voltage, low quiescent current, low drop-out regulator[J].IEEE J. of Solid-State Circuits.1998, 33(1):36-44[5]Chava C K, Silva-Martnez J. A frequency compensation scheme for LDO voltage regulators[J].IEEE Trans. on Circuits Syst. I: regular paper.2004, 51(6):1041-1050[6]Lee C K, Park H J. All-CMOS temperature independent current reference[J].Electronics Letters.1996, 32(14):1280-1281[7]Leung K N, Mok P K T. Analysis of multistage amplifier-frequency compensation[J].IEEE Trans. on Circuits Syst. I: Fund. Theory Appl.2001, 48(9):1041-1056[8]Razavi B. Design of Analog CMOS Integrated Circuits. Boston, MA: McGraw-Hill, 2001: 361-371.[9]Rincon G A. Active capacitor multiplier in Miller compensated circuits[J].IEEE J. of Solid-state Circuits.2000, 35(1):26-32[10]Thandri B K, Silva-Martinez J. A robust feedforward compensation scheme for multistage operational transconductance amplifiers with no Miller capacitors[J].IEEE J. of Solid-State Circuits.2003, 38(2):237-243[11]Fan Xiaohua, Mishra C. Single Miller capacitor frequency compensation technique for low-power multistage amplifiers[J].IEEE J. of Solid-State Circuits.2005, 40(3):584-592
