二維線性相位FIR數字濾波器的優化設計
Optimum Design of 2-D Linear-Phase FIR Digital Filters
-
摘要: 該文提出了一種用神經網絡算法來設計二維線性相位數字濾波器的新方法。通過分析二維FIR線性相位濾波器的幅頻響應特性，建立了神經網絡算法。根據給定的幅頻響應指標，按該算法可獲得濾波器系數。為保證該算法的穩定性，提出并證明了該算法的收斂定理。文中給出了圓對稱和矩形對稱二維低通線性相位FIR數字濾波器優化設計實例。計算機仿真結果表明由該方法設計的二維數字濾波器，通帶和阻帶范圍波動小，所需計算量非常少，穩定性強，因而是一種優異的設計方法。Abstract: This paper provides a new design approach based on a Neural Networks Algorithm(NNA). According to the amplitude-frequency response characteristics of 2-D FIR linear-phase filters ,the NNA is established .Using the NNA,the designed filter coefficients can be obtained from the specified amplitude-frequency responses.To ensure stability of the NNA, the convergence theorem of the NNA is presented and proved. Two examples including circularly-symmetric and quadrately-symmetric 2-D lowpass linear-phase FIR filtsrs are also given to illustrate the effectiveness of the NNA-based design approach,and the results show that the ripple is considerably small in passband and in stopband,and the NNA-based method is of strong stability and requires significantly little amount of computations.Therefore,the optimal design approach is effective and excellent in the design field of 2-D linear phase FIR digital filters.
-
Huang T S. Two-dimensional windows[J]. IEEE Trans.on Audio Electroacoust, 1972, 20(3): 80-90.[2]Speake T C, Mersereau R M. Anote on the use of windows for 2-D filter design[J].IEEE Trans. on ASSP.1981, 29(2):125-127[3]Merserau R M, et al.. McClellan transformations for 2-D digital filtering[J]. IEEE Trans.on Circuits Syst. I, 1976, 3(7): 405-413.[4]Nguyen D T, Swamy M N S. Formulas for parameters scaling in the McClellan transform[J].IEEE Trans.on Circuits Syst.1986, 33 (1):108-109[5]Algazi V R, et al.. Design of almost minimax FIR filters in one and two dimensions by WLS techniques[J].IEEE Trans.on Circuits Syst.1986, 33 (6):590-596[6]Hsieh C H, Kuo C M, Jou Y D, et al.. Design of two- dimensional FIR digital filters by a two- dimensional WLS technique[J].IEEE Trans.on Circuits Syst. II.1997, 44 (5):348-412[7]Charalambous C. The performance of an algorithm on minimax design of two- dimensional linear phase FIR filters[J].IEEE Trans. on Circuits Syst.1985, 32(10):1016-1028[8]Lang M, Selesnick I W, Burrus C S. Constrained least squares design of 2-D FIR filters[J].IEEE Trans. on Signal Processing.1996, 44 (5):1234-1241[9]Tseng Chien-Cheng. Design of 1-D and 2-D variable fractional delay allpass filters using weighted least-square method[J].IEEE Trans. on Circuits Syst. I.2002, 49 (10):1413-1422[10]Zhu W P, Ahmad M O, Swamy M N S. A closed form solution to the least square design problem of 2-D linear phase FIR filters[J].[11]IEEE Trans. on Circuits Syst. II, 1997,12 (44): 1032-1039.[12]Lu W S. Aunified approach for the design of 2- D digital filtersvia semidefinite programming[J].IEEE Trans.on Circuits Syst. I.2002, 49 (6):814-825[13]Charalambous C. The performance of an algorithm on minimax design of two- dimensional linear phase FIR filters[J].IEEE Trans. on Circuits Syst.1985, 32 (10):1016-1028 -
