有源多線圈耦合網絡網孔方程的直接建立算法
DIRECT ALGORITHM FOR FORMING MESH EQUATIONS OF THE ACTIVE MULTI-WINDING COUPLED NETWORK
-
摘要: 本文在提出了用回路描述電路元件的拓?fù)浣Y(jié)構以后,給出了具有受控源和多線圈耦合的平面網絡網孔方程的直接建立算法。網絡方程的個數等于網絡的網孔數。本文方法得到的網絡方程在此類網絡中比改進節點法方程數少,與一般節點法相比,方程建立的過程簡單明了,只需對各元件的拓?fù)浣Y(jié)構和參數進行檢索即可。
-
關鍵詞:
- 有源網絡; 互感電路; 回路分析; 直接算法
Abstract: The topological expressions of the circuit elements with meshs are put forward. Then, direct algorithm of mesh equations of the active multi-winding coupled network, which is planar, is formulated. The number of the network equations equals the mesh number of the network. It is less than the equations of the modified nodal approach. The procedure of forming equations of this algorithm is simpler than that of the current nodal and the loop approach. -
葉金官編.電路的計算機輔助分析.北京:高等教育出版社,1984,第一章.[2]Desoer C A, Kuh E S. Basic Circuit Theory. New York: McGraw-Hill Book Co., 1969, Chapter 10.[3]雷海亮.電子科學學刊,1991,13(4): 365-371. -
