一種新型探地雷達天線的FDTD分析
FDTD Analysis of a Novel GPR Antenna
-
摘要: 探地雷達系統一般采用超寬帶短脈沖信號，因而其天線系統也必須為寬帶的。該文給出一種新型的探地雷達天線，該天線為置于鏡像面上且具有離散指數電阻加載的單偶極子。通過FDTD法對該天線輻射特性的仿真計算表明，選擇合適的電阻加載方式，可以消除由于天線末端阻抗不匹配而引起的二次反射，使天線具有較好的輻射波形和一定的帶寬，從而滿足實際探地雷達系統的需要。文中還分析了收發天線不同組合方式對直耦信號和目標回波信號的影響。
-
關鍵詞:
- 探地雷達天線;FDTD方法;廣義完全匹配吸收層
Abstract: The Ground-Penetrating Radar (GPR) systems usually use broadband electromagnetic pulse, so the antennas must be wideband and can couple electromagnetic energy into the ground. A novel GPR antenna that the dipole with discrete exponential resistive loading is above the image plane is present in this paper. Radiation characteristics of the antenna are researched through the Finite Difference Time Domain (FDTD) method. The results show that the antenna in the paper terminates the reflections at the end of antennas through resistive loading, and it can be applied in GPR systems. Several different modes of employed antennas to influence the coupled signal and the scatter signal are also studied. -
