多階振幅量化加權二維固態有源相控陣天線的設計與分析
DESIGN AND ANALYSIS OF MULTI-STEP AMPLITUDE QUANTIZATION WEIGHTED 2-D SOLID-STATE ACTIVE PHASED ARRAY ANTENNAS
-
摘要: 本文論述了一種多階振幅量化二維固態有源相控陣天線獲得低副瓣的口徑設計方法,這種方法可適用于任意復雜口徑天線。另外,對于由隨機幅相誤差和單元(或T/R組件)失效而引起的副瓣電平惡化和增益下降也進行了分析。
-
關鍵詞:
- 固態有源相控陣天線; 多階振幅量化; 低副瓣; 幅相誤差; 增益損失; 失效
Abstract: An aperture design technique using multi-step amplitude quantization for two-dimensional solid-state active phased arrays to achieve low sidelobe is described. It can be applied to antennas with the arbitrary complex aperture. Also, the gain drop and the sidelobe degradation due to random amplitude and phase errors and element (or T/R module) failures are investigated. -
Slcolnik M I,et al. IEEE Trans. on AP, 1964, AP-12(6): 408-417.[2]Halford G J, et al. Proc. Radar82 Conf., London: 1982, 360-364.[3]Guo Y C. On Antennas and EM Theory. Proc. of 1985 Int. Symp. Bcijing: 1985, 667-671.[4]Guo Y C, et al.CIE 1986 Int. Conf. on Radar, Nanjiug:1986, 551-555.[5]Cheng H, et al. CIE 1991 Int. Conf. on Radar, Beijing: 1991,207-210.[6]Xue F Z, et al. 1992 IEEE AP-S Int. Symp., Session MP04, Chicago: 1992, 454-457.[7]Lee J J. IEEE Trans. on AP, 1988, AP-36(3): 339-344.[8]Heiao J K. Radio Science, 1984, 19(1):292-303. -
