任意旋轉對稱面共形陣互耦的分析
ANALYSIS OF MUTUAL COUPLING OF CONFORMAL ARRAYS ON ARBITRARY SURFACES WITH REVOLUTIONAL SYMMETRY
-
摘要: 本文研究了旋轉對稱面共形陣互耦的分析方法。文中提出了等效環的概念,把旋轉對稱面上不等元分布共形陣等效為等元分布的情形,簡化了共形陣的物理模型。通過把陣的任意激勵分解成與結構對稱性相匹配的一組本征激勵的線性疊加的方法,避免了大矩陣的求逆,大大的減少了運算量。這對于共形陣的分析和綜合有重要意義。
-
關鍵詞:
- 旋轉對稱; 共形陣; 互耦; 本征激勵
Abstract: This article presents the mutual coupling of conformal array on arbitrary surfaces with revolutional symmetry. The concept equivalent ring simplifies the array model in the method of equating arrays with unequal elements to arrays with the same elements in each ring. The method of decomposing the arbitrary excitation of arrays into a term of intrinsic excitations aviods the inversion of large matrixes and so reduces largely the computer tune, which is very important to the analysis and synthesis of conformal arrays. -
Kummer W H. Integrated Conformal Array. Final Report by Hughes Aircraft Company, Mar. 1970, AD-870786.[2]Gobert J F. IEEE Trans. on AP, 1974, AP-22(1), 87-91.[3]Gobert J F. Cylindrical Conical and Spherical Antenna Array: [Ph. D. thesis]. Chicago Illinois Institute of Tech., 1969.[4]James J R, Hall P S. Hornbook of Microstrip Antennas. London: IEE, Peter Peregrinus Ltd, 1989, Chapter 16.[5]Borgiotti G F. Conformal Array on Surfaces with Rotational Symmetry. Proc. of the 1970 Phased Array Antenna Sym., Frmingdale, New York: Jan. 1970, 301-314.[6]Rudge A W. The Handbook of Antenna Design. London: IEE, Peter[7]Ltd,1974, Chapter.[8]Balzano Q, bowling T B. IEEE Trans. on AP, 1974, AP-22(1), 92-97. -
