基于電路三要素理論的2-5混值/十值計數器研究
Research of 2-5 Mixed-Valued/Ten-Valued Counter Based on Three Essential Circuit Elements
-
摘要: 通過對2-5混值編碼原理、電路三要素理論和N +1值代數理論的分析，定量研究了2-5混值門電路、觸發器和帶進位/借位的加減法計數器，最后設計了2-5混值/十值譯碼電路，使計數器輸出為十值信號。與以往十值電路的設計方法相比較，此設計方案具有編碼效率高、供電電壓低等特點。計算機模擬驗證了上述理論和依此理論設計的電路的正確性。Abstract: By analyzing the principle of 2-5 mixed-valued coding, the theory of three essential circuit elements and the theory of N+1-valued algebra, the 2-5 mixed-valued gate circuits, flip-flops and up-down counters with carry/borrow bit are investigated quantitatively, the 2-5 mixed-valued/ten-valued encoder is designed in order to make the output of counter become ten-valued signal. Compared with the conventional design of ten-valued circuits, the design has the characteristics of high coding efficiency, low voltage supply, etc. Above theory and circuits based on this theory are verified by computer simulations.
-
吳訓威著. 多值邏輯電路設計原理[M]. 杭州：杭州大學出版社，1994: 1-385.[2]杭國強, 吳訓威. 基于開關信號理論的控閾技術與三值ECL施密特電路[J]. 電路與系統學報, 1998, 3(2): 15-20.[3]吳訓威，陳偕雄 2-3混值編碼與混值計數器[J]. 中國科學(A[4]，1989，8：848-855.[5]吳訓威, 汪鵬君, 夏銀水. 三值施密特觸發器的時序特征及其設計[J]. 電路與系統學報, 2000, 5(3): 72-74.[6]汪鵬君，盛法生，吳訓威. 四值施密特電路設計[J]. 浙江大學學報, 2001, 28(4): 462-467.[7]方振賢, 劉瑩. 三值電路和電路三要素理論[J]. 電子科學學刊, 1999, 21(4): 536-542.[8]方振賢，汪鵬君，劉瑩. 二值、多值和絕熱電路通用的電路理論[J]. 電子學報, 2003, 31(2): 303-305.[9]汪鵬君，方振賢，黃道，吳訓威. 基于電路定量理論的五值門電路和觸發器設計[J].固體電子學研究與進展, 2004, 24(2): 200-204.[10]方振賢，劉瑩. 邊沿取樣電路和同步動態時序電路綜合[J]. 電子學報, 1999, 27(5): 11-14. -
