1.3m InGaAsP/InP雙異質結發光二極管的研究
STUDY OF 1.3m InGaAsP/InP DOUBLE HETEROJUNCTION LIGHT EMITTING DIODES
-
摘要: 正 隨著光纖通信系統的發展,長波(1.11.7m)光源的研究巳廣泛引起重視。因為在這一波長范圍內,石英光纖具有低的傳輸損耗和材料色散。文獻[1]指出,用InGaAsP/InP發光二極管(=1.3m)作光源的系統的傳輸容量比目前常見的用GaAlAs/GaAs發光
-
關鍵詞:
Abstract: InGaAsP/InP double heterostructure material was grown by liquid phase epitaxial technique and Burrus type light emitting diodes were made from it. The output power is 1 m W at 100mA driving current. The emission wavelength is 1.3 m and the operating time has reached 3 103 hours.The I-V, I-P charaeteristics and the emission spectrum of the light emitting diodes are discussed. And it is pointed out that the structure of the device and the fabrieation technique do have influence upon the characteristics of the light emitting diodes,and the emission spectra of certain light emitting diodes have two peaks, it is due to the p-n junction displacement. -
W. M. Muska, et al., Electron Lett., 13(1977), 605.[2]A. G. Dentai, Electron Lett., 13(1977), 484.[5]安部正幸,信學技報,78(1979), 73.[6]王祥熙,方敦輔等,半導體光電,1981年,第2期,第209頁.[7]楊易等,半導體光電,1981年,第2期,第199頁.[8]陳自姚等,半導體光電,1981年,第2期,第207頁.[9]鄔祥生等,半導體光電,1981年,第2期,第186頁.[10]陳瑞璋等,光纖通訊,1980年,第2期,第89頁.[11]何樑昌等,通信學報,(待發表).[12]宇治俊男,昭和54年通信學會半導體材料部門全國大會演講集,1977年,第326頁. -
