星載合成孔徑雷達系統偏航控制的精確計算
Precise Computation of Yaw-Steering in Spaceborne Synthetic Aperture Radar System
-
摘要: 該文詳細推導了星載合成孔徑雷達系統中偏航控制角的精確計算公式；由于推導過程中衛星軌道采用了標準的橢圓軌道模型和地球的橢球體模型，從而解決了傳統的近似計算方法所帶來的殘余偏差較大的問題。所得結果普遍適用于不同軌道和雷達參數的星載合成孔徑雷達系統。文中同時給出了一種快速的近似計算方法，最后給出了采用TerraSAR-X系統參數時的仿真計算結果。利用該文提出的計算方法，采用偏航控制的多普勒中心校正誤差可以達到0.01Hz量級，從而實現了偏航控制的精確計算。
-
關鍵詞:
- 星載合成孔徑雷達;多普勒中心;偏航控制
Abstract: In this paper, an advanced method in precisely computing of yaw-angle in space-borne Synthetic Aperture Radar (SAR) system is proposed in detail. Standard elliptical orbit model as well as earth ellipsoid model is assumed in the course of development, thus the bias caused by conventional approximation is eliminated. The result of this paper is popular for different kind of space-borne SAR system. A simple algorithm suitable to fast computation for space-born SAR system is also exploited in this paper. The result of simulation in condition of TerraSAR-X system is given in the end. By using the computing method of this paper, emendation error after yaw-steering can be reduced to centesimal Hz level. Thus, precise computation of yaw-steering is successfully achieved. -
Hartmut Runge. Benefits of antenna yaw steering for sar. IGARSS91 Proc. Volume I, June 3-6, 1991: 257-261.[2]王睿，楊汝良. 橢圓軌道下雷達多普勒特性估計[J].電子與信息學報.2004,26(1):107-111瀏覽[3]高祥武. 星載聚束模式合成孔徑雷達系統研究. [博士論文]，中國科學院研究生院，2004年6月.[4]Ranney R K. Doppler properties of radars in circular orbits[J].Int. J. Remote Sensing.1986,7(9):1153-1162[5]孟云鶴，尹秋巖，戴金海. SAR衛星多普勒頻移偏航導引補償效果分析. 中國空間科學技術，2004，2(1): 45-49.[6]Gordon W, Ian Cumming. Signal properties of spaceborne squint-mode sar[J].IEEE Trans. on Geoscience and Remote Sensing.1997,35(3):611-617[7]Fitch J Patrick, Burrus C S. Synthetic aperture radar. Springer-Verlag, 1988: 53-57. -
