地下三維目標電磁散射的矩量法計算
Scattering from 3-D Targets in the Subsurface Using MOM
-
摘要: 該文給出了一種用層狀介質中的混合勢積分方程(MPIE)和基于RWG基函數的矩量法計算地下三維目標電磁散射的精確快速實施方法。對MPIE的RWG矩量法的開發、計算性能做了研究，尤其是對其中的多個不同形式的Sommerfeld積分的快速全波數值離散復鏡像計算方法做了仔細研究。該文的實施方法退化到自由空間后的計算結果與解析解Mie Series吻合的很好，而且地下平板的計算結果也與以往公布結果吻合得很好，證實了該文實施方法的可行、高效、精確。除此以外，該文還計算了其它形狀目標在不同大小、不同埋藏深度、以及不同地層媒質下的電磁散射特征。Abstract: In this paper, an accurate and efficient implementation approach of the Method of Moments (MOM) is developed to compute scattering from 3-D targets in the subsurface, which is based on the Mixed Potential Integral Equation (MPIE) in layered media and the RWG basis function. The implementation skill and computing performance of the proposed approach are studied in detail. In particular, how to efficiently calculate various different Sommerfeld integrals (SIs) is numerically investigated with the discrete complex images technique. The computed results of the targets in free space are in agreement with Mie Series results and the computed results of subsurface flat are also in agreement with the published data, which shows the reliability, efficiency and accuracy of the developed approach. Furthermore, the EM scattering of other shaped targets is computed at different size, buried depth, and subsurface medium.
-
Michalski K A, Mosig J R. Multilayered media Greens functions in integral equation formulations[J].IEEE Trans. on Antennas and Propagation.1997, 45(3):508-519[2]Harrington R F. Field Computation by Moment Methods. New[3]York:Macmillan,1968, Melboume, FL: Krieger, reprint 1982.[4]Chao J C, Liu Y J, Rizzo F J, Martin P A, Udpa L. Regularized integral equations for curvilinear boundary elements for[5]electromagnetic wave scattering in three dimensions. IEEE Trans[J].on Antennas and Propagation.1995, 43:(12):1416-1422[6]Hua Y, Sarkar T K. Generalized pencil-of-function method for extracting poles of an EM system from its transient response[J].IEEE Trans. Antennas Propagat.1989, 37(2):229-234[7]Aksun M I. A robust approach for the derivation of closed-form Greens functions[J].IEEE Trans. Microwave Theory Tech.1996, 44(5):651-658[8]盛新慶. 計算電磁學要論. 北京：科學出版社，2004: 21-27.[9]Rao S M, Wilton D R, Glisson A W. Electromagnetic scattering by surfaces of arbitrary shape. IEEE Trans. Antennas Propagation., 1982, AP-30(3): 409-418. [8] Fang D G, Yang J J, Delisle G Y. Discrete image theory for horizontal electric dipoles in a multilayered medium. IEE Proc.-H, 1988, 135(5): 297-303.[10]Pasi Yla-Oijala, Matti Taskinen. Efficient formulation of closed-form Greens functions for general electric and magnetic sources in multilayered media[J].IEEE Trans. on Antennas and Propagation.2003, 51(8):2106-2115[11]Cui T J, Wiesbeck W, Herschlein A. Electromagnetic scattering by multiple three-dimensional scatterers buried under multilayered mediaPart II: Numerical implementations and results[J].IEEE Trans. Geosci. Remote Sensing.1998, 36(2):535-546 -
