規范化分段線性化網絡的可控開關模型
THE CONTROLLED-SWITCH MODELS FOR CANONICAL PIECEWISE-LINEAR NETWORK
-
摘要: 本文提出應用PSpice提供的可控開關和多維受控源構成各種規范化分段線性化器件的模型,它使得可用PSpice來分析一般的規范化分段線性化網絡,這是有工程意義的。文中有詳盡的算例。
-
關鍵詞:
- 規范化分段線性化; 模型; PSpice; 可控開關
Abstract: In this paper, the models of canonical piecewise-linear devices are constructed by the controlled-switch and controlled-source of multidimensions, which are supported by PSpice. So that, the general canonical piecewise-linear network can be analyzed with the PSpice. The models present an engineering application value. The examples are discussed in detail also. -
Chua L O, Kang S M. Section-wise piecewise-linear function: Canonical representation, properties,[2]and applications. IEEE Proc. 1977, 65(6): 915-927.[3]Chua L O, Ying P R L. Canonical piecewise-linear analysis. IEEE Trans. on CAS, 1983, CAS-30(3): 125-140.[4]Chua L O, Deng A C. Canonical piecewise-linear analysis: part II-Tracing driving-point and transfer characteristics. IEEE Trans. on CAS, 1985, CAS-32(5): 417-443.[5]Chua L O, Deng A C. Canonical piecewise-linear analysis: Generalized breakpoint hopping algorithm.[6]Int. J. Circuit Theory and Appl., 1986, 14(1): 35-52.[7]溫鄭銓.規范化分段線性化動態網絡的高效算法,電子學報,1990, 18(6): 85-91.[8]溫鄭銓,陳玉燕.含特線曲線族器件的規范化分段線性化動態網絡的算法[J].電子科學學刊.1994, 16(3):275-283[9]溫鄭銓.規范化分段線性化動態網絡的改進節點法.電子學報,1994, 22(8): 87-90.[10]Rashid M H. Spice for Circuits and Electronics Using PSpice. New Jersey: Prentice-Hall Inc., 1990, Chapt. 4-5.[11]Kennedy M P, Chua L O. Hysteresis in electronic circuits: A circuit theorists perspective[J].Int. J. Circuit Theory and Appl.1991, 19(3):471-515 -
