開關電容振蕩器的起振和幅值穩定的研究
STUDY OF START-OSCILLATION AND AMPLITUDE-STABILIZATION OF SC OSCILLATORS
-
摘要: 本文討論了開關電容振蕩器(SCO)的起振和幅值穩定問題。提出了SCO的起振和幅值穩定的新方法。給出了穩定性好的幅值控制電路。在多相SCO的設計中,幅值控制電路的復雜程度不隨振蕩器的相數增加而增加。實驗結果與理論相符。
-
關鍵詞:
- 開關電容振蕩器; 起振; 幅值穩定
Abstract: How to start oscillation and how to stabilize amplitude in SC oscillators are discussed. New methods for start-oscillation and amplitude-stabilization of SC oscillators are presented. The control circuitry with good stability for amplitude-stabilization is given. It is shown that the complexity of the amplitude-stabilization circuitry does not increase as the number of oscillator phases in the multiphase oscillator increases. The experimental results are in agreement with the presented theory. -
楊永明,電子科學學刊,10(1988)6, 491-500.[2]W. B. Mikhae, S. Tu, IEEE Trans. on CAS, CAS-31(1984), 280-291.[3]R. Gregorian, K. R. Matin, G. C. Temes, Proc. IEEE, 71(1983) 8, 941-965.[4]E. Vittoz, IEEE J. of SC, SC-14 (1979) 3. 644-647.[5]R. P. Colbeck, IEEE J, of SC, SC-19 (1984) 6, 996-998.[6]P. E. Fleischer, A. Ganesun, K. R. Laker, IEEE J. of SC, SC-20 (1985) 2, 641-647.[7]G. C. Temes.[J].Electron. Lett..1978,14:9- -
