基于雙曲線特征的淺地層探地雷達雜波抑制與合成孔徑成像研究
Research on Clutter Reduction and Synthetic Aperture Imaging of Shallow Subsurface Ground Penetrating Radar Based on Hyperbolic Feature
-
摘要: 本文根據淺地層探地雷達圖像的特點，提出了一種基于圖像處理技術的雜波抑制方法。并在此基礎上，進而提出了一種實現探地雷達合成孔徑成像的快速方法。通過對實測數據進行處理，結果表明，所提雜波抑制方法取得了很好的效果，且通用性強；所提的快速合成孔徑成像方法與普通合成孔徑成像方法相比，所得圖像的分辨力相當，且所提方法減少了雜波成分的影響，使處理速度得到了極大的提高，成像的效果更好。
-
關鍵詞:
- 探地雷達;雜波抑制; 合成孔徑成像; 圖像處理
Abstract: This paper proposed a new clutter reduction method based on characteristic of Ground Penetrating Radar(GPR) image in detecting shallow subsurface objects. Moreover, a method to realize fast synthetic aperture imaging based on the proposed clutter reduction method is proposed. The results of processing measurement data show the proposed clutter reduction method is very effective and universally valid; The resolving power of image gained by the proposed fast synthetic aperture imaging method corresponds with that general synthetic aperture imaging method, thanks to the proposed method can eliminate the influence of clutter, so the processing speed is improve greatly comparing with general synthetic aperture imaging method, the effect of image gained by the proposed method better than general synthetic aperture imaging method. -
Scheers B. Ultra-wideband ground penetrating radar with application to the detection of anti personnel landmines. [Ph.D thesis], Brussels, Royal Military Academy, 2001.[2]Gurel L, Oguz U. Optimization of the transmitter-receiver separation in the ground-penetrating radar[J].IEEE Trans. on Antennas and Propagation.2003, 51(3):362-370[3]孔令講, 周正歐. 淺地層探地雷達波速測量方法的研究[J]. 電子學報, 2002, 30(9)：1330-1332.[4]Andria van der Merwe, Inder Gupta J. A novel signal processing technique for clutter reduction in GPR measurements of small, shallow land mines[J].IEEE Trans. on Geoscience and Remote Sensing.2000, 38(6):2627-2637[5]Daniels D J. Surface Penetrating Radar [M]. London, UK: Published by IEE, 1996.[6]Osuni N, Ueno K. Detection of buried plant[J]. IEE Proc.-F,[7]88, 135(4): 330-342.[8]孔令講，周正歐. 淺地表探地雷達中改善成像分辨力的一種有效方法[J]. 信號處理，2002，18(6)：505-508.[9]Xu Xiaoyin, Eric Miller L. A statistical method to localize buried landmines from GPR array measurement[C].SPIE, 2001, (4394): 742-753.[10]孔令講. 淺地層探地雷達信號處理算法的研究[D]. [博士論文],成都: 電子科技大學, 2003.[11]王新成. 高級圖像處理[M]. 北京：中國科學技術出版社，2001: 47-50.[12]Al-Nuaimy W, Huang Y, Shihab S. Automatic target detection in GPR data[C]. SPIE, 2002, (4758): 139-143. -
