基于TCL的電路板原理圖自動審查平臺建設
An Auto-verification Platform for Schematic Design Based on TCL
-
摘要: 該文提出了一種用TCL語言作為審查腳本語言構造原理圖審查系統的系統框架。在該系統中,利用TCL語言的擴展性,制定了一套應用于原理圖通用數據結構的TCL擴展命令,并在此基礎上構建原理圖規則庫和自動審查執行器,實現了原理圖的自動審查。Abstract: In this paper, an auto-verification platform for schematic design is presented based on the extended TCL as a script language. Using the extensible property of the TCL, constructed a set of extended TCL command on the general data structure of the schematic design, and on this base, a rule library and an auto-verification runner are built to make the auto verification of the schematic design possible.
-
蔡固順,饒勇,李玉山.電子自動化設計數據的標準格式問題.電子科技,1998,(6):18-21.[2]John Ousterhout. Tcl and the Tk Toolkit. Boston, MA: Addison-Wesley Publishing Company, 1993:2 - 389. -
