用CCII回轉器設計梯形結構電流模式濾波器

王春華,  沈光地,  徐晨,  李建軍,  史辰,  郭霞

王春華, 沈光地, 徐晨, 李建軍, 史辰, 郭霞. 用CCII回轉器設計梯形結構電流模式濾波器[J]. 電子與信息學報, 2001, 23(5): 516-520.
引用本文: 王春華, 沈光地, 徐晨, 李建軍, 史辰, 郭霞. 用CCII回轉器設計梯形結構電流模式濾波器[J]. 電子與信息學報, 2001, 23(5): 516-520.
Wang Chunhua, Shen Guangdi, Xu Chen, Li Jianjun, Shi Chen, Guo Xia. DESIGNING HIGH-ORDER CURRENT MODE FILTER WITH LADDER STRUCTURE USITNG CCII GYRATOR[J]. Journal of Electronics & Information Technology, 2001, 23(5): 516-520.
Citation: Wang Chunhua, Shen Guangdi, Xu Chen, Li Jianjun, Shi Chen, Guo Xia. DESIGNING HIGH-ORDER CURRENT MODE FILTER WITH LADDER STRUCTURE USITNG CCII GYRATOR[J]. Journal of Electronics & Information Technology, 2001, 23(5): 516-520.

用CCII回轉器設計梯形結構電流模式濾波器

DESIGNING HIGH-ORDER CURRENT MODE FILTER WITH LADDER STRUCTURE USITNG CCII GYRATOR

  • 摘要: 該文提出一種設計高階CCⅡ(第二代電流傳輸器)電流模式濾波器的新方法,即用CCⅡ回轉器綜合電流模式無源梯形網絡的輸入導納,從而設計出高階電流模式CCⅡ?yàn)V波器。用該方法設計出的電路與其它同類電路比較,電路結構簡單、所使用的CCⅡ數目少。文中對CCⅡ的非理想特性進行了分析,提出了對CCⅡ的非理想特性進行補償?shù)姆桨?。文中給出了六階巴特沃斯濾波器的設計舉例及補償前和補償后的計算機PSPICE仿真結果。
    Abstract: This paper presents a new method of designing high-order CCII filter.The method is synthesizing input immittance of passive ladder network by CCII gyrators and realizing high-order current mode CCII nlter.The paper analyzes non-ideal character of CCII and gives out the compensation method. Compared with other similar circuits, the designed circuit using this method has simpler structure and fewer number of CCIIs. Design example of 6-th order Butterworth filter and its computer PSPICE imitation results before compensation and after compensation are also given.
    • HTML全文
  • G,W,Riberts,A.S.Sedra.All current-mode frequency selective circuits,Electron .Lett,1989,25(12),759-761.[2]Y.Sun,J.K.Fidler,Versatile active biquad based on second-generation current couveyor,Iuter.J.of Electron,1994,76(1):91-98.[3]Chang C M,Chen P.Universal active current filter with three imputs and one output using current conveyors,Inter.J.of Electron,1991,71(5),817-819.[4]Chang C M.Chen C C.Wang H Y,Universal active current filter with three inputs using current conveyor-Part 2.Iuter,J.of Electron ,1994,76(1),81-89.[5]M.J.Abuelmaarti,A.M.Shabra,A novel current conveyer-based universal current-mode fillter,Microelectronics Journal,1996,27(6):471-475.[6]A .M.Soliman Current conveyer filters,classification and review,Microelectronics Journal ,1996,29(3),133-149.[7]王春華,鄭潔如.基于CCII的多功能電流模式濾波器,微電子學, 1998,28(5),311-315.[8]E.O.Gunes.F.Anday.Realization of current-mode filter low-pass filters using CFCCIIs,Electron,Lett,1995,31(25),2161-2162.[9]王春華,嚴光文,用信流圖法設計N階CCII電流模式濾波器,固體電子學研究與進展, U99,19(1),38-42.[10]韓慶全,郭靜波,電流模式全極點跳粥結構濾波器,電子科學學刊,1994,16(5,)505-511.[11]白宮標.吳杰.洪瀾,尹新,具有跳結構電流模式濾波器設計,電子科學學刊1996.18(2).213-216.[12]Wu J,E.E.Masry,Current-mode ladder filters using multiple output current conveyors,IEEE Proc-G,1996,143(4),218-222.[13]W.Surakampontorn,V.Kiewruja,K.Kumwachara,et al.Accurate CMOS-based current conveyers,IEEE Trans.on Instrumentation and Measurement,1991,IM-40(4),699-702.
  • 加載中
計量
  • 文章訪問數:  2417
  • HTML全文瀏覽量:  97
  • PDF下載量:  430
  • 被引次數: 0
出版歷程
  • 收稿日期:  1999-04-14
  • 修回日期:  2000-01-24
  • 刊出日期:  2001-05-19
