電控體效應振蕩器相位的新方法
A NEW mm WAVE GUNN OSCILLATOR PHASE-LOCKING METHOD
-
摘要: 以往國內外采用種種鎖相方法,而直接控制體效應振蕩器偏壓的鎖相法則被認為是不切實際的方法。本文作者在實驗上成功地克服了文獻[1]所提出的困難,運用直接控制體效應振蕩器偏壓的方法實現了8mm(35GHz)鎖相標準頻率源和8mm固定中頻鎖相跟蹤系統,本文分析了這種新的鎖相方法所具有的獨特優越性并給出了實驗結果。
-
關鍵詞:
Abstract: Reference [1] concluded that for the phase-locking of Gunn Oscillator, timing by varying the bias voltage on the diode is not a practical method. However the author of this paper successfully realized the 8mm (35 GHz) phase-locking standard fre-quency source and 8 mm fixed intermediate frequency phase-locking tracker with this method. This paper analyzes also the unique advantage of the new method. The ex-perimental results are given. -
J.Baprawski, C. Smith and F. J. Bernues, Microwave Journal,19(1976), 41.[2]G.S. Hobson, The Gunn-Effect,Clarendon Press, Oxford,1974,p.94-96.[3]J.Robert Ashley et al., IEEE on MTT, MTT-25(1977),294. -
