波導結和波導-喇叭輻射器有限元分析導波數值邊界條件及其應用
WAVEGUIDE JUNCTION AND GUIDE-HORN RADIATOR ANALYSIS-GUIDED-WAVE NUMERICAL BOUNDARY CONDITIONS AND THEIR APPLICATIONS
-
摘要: 作為開域電磁場問題偏微分方程解法的一個重要方面,本文提出導波致值邊界條件的概念和算法。本文著重討論二維的具有平面導體邊界的導波系統的散射和輻射問題,并以此表明基于數值邊界條件的偏微分方程的數值解法,將為波導-喇叭輻射器的準確分析開辟了新的理論途徑。Abstract: As an important aspect of partial differential equation solutions of open-region electromagnetic field problems, the concept and algorithm of guided-wave global numerical boundary conditions are presented. Emphasis is placed on the two-dimensional guided-wave scattering and radiation analysis in the waveguides with plate-conducting boundaries. This analysis method can be readily expanded to cover many other guided-wave systems, leading to a new theoretical approach to the guide-horn like radiator analysis.
-
Desen Fan, Two-Dimensional Scattering Analysis by Global Numerical Boundary Condition Based PDE Techniques, 3rd International Symposium on Recent Advances in Microwave Technology, Nevada, USA, Aug. 1991.[2]樊德森,二維多體散射系統分析,電子科學學刊, 14(1992)3,252-258.[3]樊德森,多端口矩形波導E面波導結數值分析,電子學報,19(1991)4,71-78.[4]R. W. Charstein, IEEE Trans, on AP, 61P-37(1989)11, 1415-1426.[5]K. Hongo, Radio, Science, 7(1972)10, 955-963. -
