單槍彩色密封油膜光閥管的電子槍與偏轉聚焦系統的對中要求
THE EVALUATION OF THE ALIGNING TOLERANCEBETWEEN THE ELECTRON GUN AND THE DFS INTHE SEALED LIGHT VALVE TUBE
-
摘要: 正 單槍彩色密封油膜光閥管的原理和結構見文獻[1]。它的電子槍和偏轉聚焦系統由于不是整體對中裝配,因此存在對中公差的要求。由于電子槍的電極尺寸和各電極之間的距離可以確定,電子束的光斑大小可從電子槍的通過率和限制膜孔的大小推算出,所以電子槍與偏轉聚焦系統的對中公差要求可以據此進行估計。 (一)電子槍和偏轉聚焦系統的結構 單槍彩色油膜光閥管的電子槍是皮爾斯槍,在陽極上有限制膜孔。 偏轉聚焦系統包括:小偏轉板、預偏轉板、主偏轉板和漂移環等。其中預偏轉板、主
-
關鍵詞:
Abstract: This paper describes the functions of both the toroidal alignment coil and the centering deflection plates in the sealed light valve tube. If the electrode sizes, the spaces between electrodes and the electron beam transparency are known, the spot size and the aligning tolerance between the electron gun and DFS(deflection focus system) can be evaluated. -
W. E. Glenn, SMPTE. 79(1970), 788. -
