波導本征值問題的有限元分析
THE FINITE-ELEMENT ANALYSIS OF WAVEGUIDE EIGENVALUE PROBLEM
-
摘要: 本文簡要討論了波導本征值問題的有限元分析方法。給出了一個用有限元法求解波導本征值問題的標準程序。使用該程序可以獲得一大類橫截面周界由直線及圓弧圍成的波導的各個本征值和本征函數。文中通過對十幾種不同結構波導本征值問題的求解,證實了該程序的可靠性。
-
關鍵詞:
Abstract: In this paper the finite-element analysis method of waveguide eigenvalue problem is briefly discussed. A standard program using finite-element method to solve waveguide eigenvalue problems is presented. With this program, it is possible to calculate the eigenvalues and eigenfunctions for a group of waveguides consisting of lines and circular arcs. The calculations of eigenvalue problems for more than ten different structure waveguides verify the reliability of the program. -
J. B. Davies and C. Eng, P. I. E. E, 119(1972), 33.[4]黃宏嘉,微波原理,科學出版社,1963年,卷(I).[5]林為干,微波理論與技術,科學出版社,1979年,第四章.[7]S. S. Saad et al., IEEE on MTT, MTT-25(1977), 437.[8]徐善駕,L形波導H10-H20波型變換器的計算機分析,電子學報,(即將發表).[9]徐善駕,H02波扇形波型變換器的改進設計,中國電子學會微波學會、中國光學學會聯合學術年會論文,1981, 6. -
