連續相位調制信號的二階循環平穩特性分析
The Characteristic Analysis of Second Order Cyclostationarity of Continuous Phase Modulation Signal
-
摘要: 連續相位調制(CPM)信號以其恒包絡和優良的頻譜特性在現代衛星通信和移動通信中越來越受到人們的重視，然而這一大類調制信號的循環平穩特性卻較少有人關注。該文根據連續相位調制信號在不同調制指數下的基帶循環譜，推導了其相應帶通循環譜的表達式, 并對這些表達式的詳細分析，得出了不同調制指數情況下循環頻率與載頻、碼元寬度和峰值頻偏之間的關系式。仿真實驗證明這些結論是正確的。
-
關鍵詞:
- 連續相位調制;循環平穩;循環譜
Abstract: Continuous Phase Modulated (CPM) signals play a prominent role in modern satellite communication systems and mobile communication systems due to their constant envelope property and bandwidth efficiencies. However, there was no much comprehensive reference concerning the cyclostationarity of the large family of CPM. In this paper, the general band-pass cyclic spectral representations of the continuous phase modulation are derived and analyzed in detail based on the analytical expression of the corresponding base-band cyclic spectra; as well, the relation between cyclic frequency and carrier frequency, code width, peak frequency deviation is obtained with the different modulation indexes. These conclusions are proved by the computer simulations. -
Laurent P A. Exact and approximate construction of digital phase modulations by superposition of amplitude modulated pulses[2]IEEE Trans. on Communications, 1986, 34(2): 150-160.[3]Mengali U , Morelli M. Decomposition of M-ray CPM signals into PAM waveforms[J].IEEE Trans. Information Theory.1995, 41(5):1265-1275[4]Garder W A. Statistical Spectral Analysis: A Nonprobabilistic Theory. Englewood Cliffs, NJ: Prentice-Hall, 1987, chap 9 chap 13.[5]Garder W A. Introduction to Random Processes: with Application to Signals and Systems. McGraw-Hill, 1990, chap 10 chap 13.[6]Garder W A. The spectral correlation theory of cyclostationary time-series[J].Signal Processing.1986, 11(2):13-36[7]Garder W A, Ed. Cyclostationarity in Communications and Signal Processing. New York: IEEE, 1994, chap 1.[8]黃春琳，姜文利，周一宇. 對低截獲概率相位編碼信號檢測的有限多循環檢測器. 電子學報， 2002，30(6)：916-918.[9]黃春琳，姜文利，周一宇. 窄帶強干擾下直接擴譜序列信號的有限多循環檢測器. 通信學報，2003，24(3)：105-112.[10]黃春琳， 柳征，姜文利，周一宇. 基于循環譜包絡的擴譜直序信號的碼片時寬、載頻、幅度估計. 電子學報，2002，30(9)：1353-1356.[11]黃知濤，姜文利，周一宇. 多循環頻率循環時延估計方法及性能分析. 電子學報，2004，32(1)：102-108.[12]黃知濤，周一宇，姜文利. 基于循環平穩特性的源信號到達角估計方法. 電子學報，2002，30(3)：372-375.[13]金梁，姚敏立，殷勤業. 寬帶循環平穩信號的二維空間譜估計. 通信學報， 2000，21(3)：7-11.[14]張賢達.非平穩信號分析與處理. 北京：清華大學出版社，1997.[15]Napolitano A, Spooner C M. Cyclic spectral analysis of continuous-phase modulated signals[J].IEEE Trans. on SP.2001, 49(1):30-44[16]Gournay P ,Viravau P. Corrlation spectrale thorique des[17]modulations CPM-PartieI: Resultat analytique pour les modulations CPFSK 2 tats(1REC). Ann. Tlcommun, 1998, 53(7/8): 267-278.[18]Viravau P, Gournay P. Corrlation spectrale thorique des modulations CPM-Partie II: Mthode de calcul gnrale et analyse[J].Ann. Tlcommun.1998, 53(7/8):279-288[19]Proakis J G. Digital Communications. Third Ed. New York: McGraw-Hill, 1995, chap 4. -
