改進寬頻帶大功率速調管等激勵功率-頻率特性的方法
METHODS FOR IMPROVING EQUIDRIVING POWER-FREQUENCY CHARACTERISTICS OF BROADBAND HIGH POWER KLYSTRONS
-
摘要: 本文提出了兩種改進寬頻帶大功率速調管等激勵功率-頻率特性的方法。其一是在行波管推動級和速調管間加入具有一定衰減特性的帶通濾波器,使之與速調管增益-頻率特性互補,以獲得所要求的等激勵增益-頻率特性;另一是在輸入腔外接電抗元件,用來改變輸入腔的諧振頻率f0和QL ,以達到改善速調管增益-頻率特性的目的。
-
關鍵詞:
- 寬頻帶大功率速調管; 等激勵頻寬; 梳線帶通濾波器; 電抗元件
Abstract: Two methods for improving the equidriving power-frequency characteristics of broadband high power klystrons are presented. One is that a comb-line bandpass filter with attenuation properties is inserted between the TWT driver and the klystron for compensating the gain-frequency characteristics of the klystron to get the required equidriving gain-frequency characteristics. The other is that a reactive element is connected with the input cavity to change its resonance frequency f0 and QL and then to improve the gain-frequency characteristics of the klystron. -
G. L. Matthaei, L. Yong, E. M. T. Jones, Microwave Filters, Impedance-Matching Networks. and Coupling Structures, McGraw-Hill, Inc., (1964), Chaptcr 8.[2]G. L. Matthaei, The Microwave Journal, 6(1963)8,82-91.[3]丁耀根,陸孝厚,電子學通訊,4(1982.)3,158-174.[4]H. Scifert et al.,鮑賢杰譯,電子管技術,1981年,第2期,第7-9頁.[5]陸孝厚,趙京君,丁耀根,Proc. of 2nd International Symposium on Recent Advance in Microwave[6]Technology, Beijing, (1989), p253. -
