FD-TD法用于環形相控振子天線陣列的數字模擬
NUMERICAL SIMULATION OF ANNULAR PHASED ARRAY OF D1POLE ANTENNAS USING FD-TD METHOD
-
摘要: 本文論述了FD-TD法用于電磁輻射系統的近場計算問題,用該方法實現了對環形相控振子天線陣列的數字模擬。作為對方法的檢驗首先計算了單個振子天線上的電流分布,還計算了環中充滿去離子水時陣列的近區場及其與人體軀干塊狀模型的相互作用。
-
關鍵詞:
- 電磁輻射系統; FD-TD法; 數字模擬
Abstract: The problems for calculating near-fields of EM radiation systems by using Finite Difference Time-Domain (FD-TD) method are discussed and the annular phased array of dipole antennas is simulated numerically by use of FD/TD method. For a test run the near-field and current distribution of the single dipole antenna are calculated. The near-field of the annular phased array of dipole antennas in central region filled with deionized water is computed and the interaction of near-field with a anatomically-based model of buman torso is considered as well. -
P. F. Turner, IEEE Trans. on MTT, MTT-32(1984), 874-882.[2]R. Spiegel, IEEE Trans. on MTT, MTT-32(1984), 730-746.[3]D. M. Sullivan, D. T. Borup, O. P. Gandhi, IEEE Trans. on BME, BME-34(1987), 148-157.[4]K. S. Yee, IEEE Trans. on AP, AP-14(1966), 302-307[5]A. Taflove, M. E. Brodwin, IEEE Trans. on MTT, MTT-23(1975), 623-630.[6]A. Taflove, IEEE Trans. on EMC, EMC-22(1980), 191-202.[7]R. Holland, IEEE Trans. on NS, NS-24(1977), 2416-2421[8]K. S. Kuzy, K-M. Lee, IEEE Trans. on EMC, EMC-20(1978), 328-332.[9]G. Mur, IEEE Trans. on EMC, EMC-23(1981), 377-382. -
