大電流時晶體管電流增益下降的物理原因
VERIFICATION OF THE PHYSICAL REASON FOR THE CURRENT GAIN FALL-OFF AT HIGH CURRENTS
-
摘要: 正 1.引言 眾所周知,晶體管的電流增益與收集極電流有關,開始它隨收集極電流增大而增大,達到一最大值后,它又隨收集極電流的進一步增大而逐漸減小。所謂大電流時電流增益下降,就是指收集極電流大于電流增益達最大值所對應的收集極電流后電流增益下降的現象。 關于大電流時電流增益下降的物理原因,過去有兩種解釋:一是由Webster提出的基區電導調制效應;另一是由Kirk提出的有效基區展寬效應
-
關鍵詞:
Abstract: Starting from the temperature characteritics of the transistor current gain, the temperature-dependent law of the collector current just as the current gain begins to fall-off is studied theoretically and experimentally. It is verified that the physical reason is the base widening effect. -
W. M. Webster, Proc. IRE, 42(1954), 914.[2]C. T. Kirk, IEEE Trans. on ED, ED-9(1962), 164.[3]R. J. Whitter and D. A. Tremere, ibid., ED16 (1969), 39.[4]D. L. Bowler and F. A. Lindholm, ibid, ED-20(1973), 257.[5]P. L. Hower, ibid, ED-20 (1973), 426.[6]R. Kumar and L. P. Hunter, ibid., ED-22(1975), 1031.[7]G. Rey, F. Dupuy and J. P. Bailbe, Solid-State Electron. 18(1975), 863.[8]C. B. Norris and J. F. Gibbons, IEEE Trans. on ED, ED-14(1967), 38.[9]F. J. Morin, Phys. Rev., 93(1954), 62.[10]E. I. Ruder, ibid, 90(1951), 766.[11]C, Kittel, Introduction to Solid State Physics, p. 94, New York, John Wiley and Sons., Inc.,1956.[12]H. F. Wolf, Silicon Semiconductor Data, Signetics Corporation, 1969, p. 32. -
