微波FET混頻器的分析與設計
ANALYSIS AND DESIGN OF MICROWAVE FET MIXERS
-
摘要: 本文討論了微波單柵FET的等效電路模型、本振大信號分析的諧波平衡法以及RF小信號分析的多頻變換矩陣法。建立了一套完整的FET混頻器的分析設計方法。試驗設計表明,本方法是簡便而有效的。
-
關鍵詞:
- FET混頻器; 變頻增益; 噪聲系數; 諧波平衡法; 多頻變換矩陣法
Abstract: The equivalent circuit model of microwave SGFET, the large signal analysis of LO injection by harmonic blance method and the small signal analysis of RF injection by multi-frequency conversion matrix method are discussed. A complete method for analysing and designing mixers in presented. The measurement results show that this method is simple and effective. -
R. A. Pucel, D. Masse, B. Bera, IEEE Trans. on MTT, MTT-24(1976), 351-360.[2]S. A. Mass, IEEE Trans. on MTT, MTT-32(1984), 1402-1406.[3]G. K. Tie, C. S. Aitcbison, Noise Figure and Associated Conversion Gain of a Microwave MESFET Gate Mixer, in i3th European Microwave Conference, (Nuremberg), 1983, pp.579-584.[4]吳萬春,集成固體微波電路,國防工業出版社,北京,1981年.[5]吳萬春,微波半導體電路CAA與CAD,西北電訊工程學院微波研究室內部資料,1987年. -
