導體球涂覆各向異性鐵氧體介質電磁散射的解析解
The Analytical Solution to the Electromagnetic Scattering by an Anisotropic Ferrite-Coated Conducting Sphere
-
摘要: 該文用球矢量波函數對各向異性鐵氧體介質涂覆導體球的電磁散射解析解開展研究。各向異性鐵氧體介質中電磁場的球矢量波函數解可表示成第一、二、三、四類球矢量波函數之和。根據球Bessel函數的性質，可以得出導體球涂覆各向異性鐵氧體介質的球矢量波函數解析解。應用鐵氧體與自由空間分界面上電磁場切向連續和在導體球面上切向電場等于零的邊界條件以及球矢量波函數切向正交性質，可分別得出鐵氧體介質中電磁場和散射場的展開系數。給出了平面波入射情況下的數值計算結果。該文的結果可應用于有關微波器件、天線以及目標特征的分析和計算。
-
關鍵詞:
- 球矢量波函數; 鐵氧體; 各向異性
Abstract: The analytical solution of electromagnetic scattering to an anisotropic ferrite-coated conducting sphere by a plane wave is discussed in this paper. It is well known that the electromagnetic fields in three-dimensional ferrite medium and free space can be expressed into spherical vector wave functions of the first, second, third and fourth in ferrite anisotropic medium and isotropic medium. Applying the continue boundary condition of tangential component of electromagnetic fields in the interface between the ferrite anisotropic medium and free space, and the tangential electric field vanishing in the interface of the conducting sphere, the expansion coefficients of electromagnetic fields with spherical vector wave function in ferrite medium and the scattering fields in free space can be derived. The theoretic analysis and numerical result show that when the radius of conducting sphere approaches zero, the present method can be reduced to that of the homogeneous ferrite anisotropic medium. The present method can be applied to the analyses of related microwave devices, antennas and the character of radar targets. -
Richmond J H. Scattering by a ferrite-coated conducting sphere. IEEE Trans. on AP, 1987, AP-35(1): 73-79.[2]Eaves R E. Electromagnetic scattering from a conducting circular cylinder covered with a circumferentially magnetized ferrite. IEEE Trans. on AP, 1976, AP-24(2): 190-197.[3]Yung E K N, Zhang D G, Wong R S K. A novel waveguide Y-junction circulator with a ferrite sphere for millimeter waves. IEEE Trans. on MTT, 1996, MTT-44(3): 454-456.[4]Chen R, Yung E K N, Xie X M, Wang Y. FDTD analysis of EW wave circulating by a magnetized ferrite body in free space[J].Int. J. of Infrared and Millimeter Waves.1998, 19(2):329-341[5]朱秀芹, 耿友林, 吳信寶. 三維磁各向異性目標電磁散射的MOM-CGM-FFT方法. 微波學報，2002, 18(3): 7-13.[6]Ren W. Contributions to the electromagnetic wave theory of bounded homogeneous anisotropic media[J].Phys. Rev. E.1993, 47(1):664-673[7]Geng Y L, Wu X B. A plane electromagnetic wave scattering by a ferrite sphere[J].J. of Electromagnetic Waves and Applications.2004, 18(2):161-179[8]Sarkar D, Halas N J. General vector basis function of Maxwell's equations[J].Phys. Rev. E.1997, 56(1):1102-1112 -
