GTEM室與開闊場的輻射測量之間關系研究
Correlation between gtem cell and open area test site in emission measurements
-
摘要: 該文詳細推導了用電、磁偶極矩展開表示的電小尺寸輻射體在 GTEM室的輻射功率與開闊場中輻射場之間的理論關系,修正了 Lee理論中相應公式,并將理論結果與標準單極子輻射源實驗結果進行了比較。結果表明兩者符合的很好。這說明 GTEM室和開闊場輻射測量具有密切的相關性。對于電小尺寸的輻射體,GTEM室不僅可以用于 EMS測試,也可用于做 EMI測試。
-
關鍵詞:
- GTEM室; 開闊場; 輻射測量
Abstract: This paper derives in detail the horizontal radiated electric fields from an elec-trically small radiator which may be well represented by the electric dipole and the magnetic moments, then the Lees corresponding formula are modified. Theoretical results compared with experimental data measured directly over OATS agree well. This shows that GTEM cell measurements are correlative with OATS emission measurements. For the electrically small radiator, GTEM cell may be used not only for EMS test but also for EMI test. -
P. Wilson, On the correlating TEM cell and OATS emission measurements, IEEE Trans. on Electromagnetic Compatibility, 1985, EMC-27(3), 137-142.[2]P. Wilson, On the correlating TEM cell and OATS emission measurements, IEEE Trans. on Electromagnetic Compatibility, 1995, EMC-37(1), 1-16.[3]Ae-Kyoung Lee, An algorithm for an advanced GTEM to ground plane correlation of radiated emission test, IEEE EMC Symposium, Seattle, 1996, 58-62.[4]任列輝,陳志雨,GTEM室與開闊場的輻射發射相關研究,電波科學學報,2002,17(1),74-77.[5]Julius Adams Stratton, Electromagnetic Theory, New York and London, McGRAW-HILL book company, 1941, 176-179, 235-237. -
