航管二次雷達發射天線方向圖綜合
Transmit antenna pattern synthesis for secondary surveillance radar
-
摘要: 該文介紹航管二次雷達(SSR)發射天線方向圖綜合的新方法,這種方法以有源相控陣天線為基礎。利用帶底座的Cosine口徑幅度分布綜合出所需的定向方向圖,輻射用于詢問的P1和P3脈沖。在上述口徑幅度分布基礎上,利用駐相法獲得所需的口徑相位分布以綜合出方位上全向的方向圖,輻射用于詢問旁瓣抑制(ISLS)的P2脈沖。省去了單獨輻射P2脈沖的天線和相應設備。
-
關鍵詞:
- 二次雷達; 方向圖綜合; 駐相法; 詢問旁瓣抑制
Abstract: A new method of transmit pattern synthesis for Secondary Surveillance Radar (SSR) is presented. This method is concerned with an active phasedarray antenna. A cosine on pedestal excitation for aperture distribution is used to synthesized the desired directional pattern, which is used to transmit the P1 and P3 pulse for interrogation. Using stationary phase method, the phase function over aperture on the specified aperture amplitude distribution is obtained and the desired pattern to transmit the P2 pulse is synthesized for Interrogation Side Lobe Suppression (ISLS). The antenna and relevant equipment which transmits only the P2 pulse is saved. -
山秀明主編,航管二次雷達,北京,國防工業出版社,1983年10月,32-35.[2]Paul R. Drouilhet, The development of the ATC radar beacon system: Past, present and future,IEEE Trans. on communications, 1973, COM-21(5), 408-421.[3]黎廷璋編著,張德馨審校,空中交通管制機載應答機,北京,國防工業出版社,1992年7月,18-21.[4]T.T. Taylor, Design of circular apertures for narrow beam width and low side lobes, IRE Trans.on Antennas propagat., 1960, AP-8(1), 17-22.[5]郭燕昌等編,相控陣和頻率掃描天線原理,北京,國防工業出版社,1978年3月,137-139[6]Richard Kinsey, Phased array beam spoiling technique, IEEE, Antennas and propagation society international symposium, 1997, 2, 698-701.[7]H.E. Shanks, A geometrical optics method of pattern synthesis for linear array, IRE Trans. on Antennas Propagat., 1960, AP-8(5), 485 490.[8]A.K. Agrawal, J. A. Mattioli, N. R. Landry, An active phased array antenna packaging scheme,IEEE, Antennas and propagation society international symposium, 1996, 3, 1608-1611.[9]Yin Liansheng, Intergralization design of T/R modules and feeding networks for solid-state activephased arrays, 1993, URSI Radio Science Meeting, U.S.A, 1993, 281-286. -
