基于多尺度分析的混沌態Boost電路的分形研究
Study on the Fractal of Chaos Signal in Boost Circuit Based on Multi-scale Analysis
-
摘要: 分形維數是混沌吸引子的重要特征參數，而小波變換是一種多尺度分析工具。該文研究了混沌信號的自相似性及其不同尺度小波變換系數的特性，推導出計算混沌信號分形維數的多尺度計算方法，并對Boost電路混沌信號的分形維數進行了仿真計算，清楚刻畫了其混沌吸引子的分形特性。
-
關鍵詞:
- 混沌;分形;小波;Boost電路
Abstract: The fractal parameter is very import in studying the chaos signal. Wavelet transform is a useful multi-scale tool for analyzing the fractal. In this paper, the self-similarity property of chaos signal and the properties of the coefficient of wavelet transform in different scales are discussed, and the signal of Boost circuit in chaotic state is studied by wavelet transform. From deduction, the algorithm of calculating the fractal parameter of the chaotic attractor of the circuit is got. Finally, the calculation and simulation are done. -
Tse C K. Recent developments in the study of nonlinear phenomena in power electronic circuits. IEEE Circuits and Systems Newsletter, 2000, 12: 14-48.[2]Heidari S, Tsihrintzis G A, Chrysostomos, et al.. Self-similar Set identification in the time scale domain[J].IEEE Transactions on Signal Processing.1996, 44(6):1568-1573[3]Fotiou I A. Fractals and wavelets. IEEE Potentials, 2003, 22(2): 28-31.[4]Daubechies I. The wavelet transform, time-frequency location and signal analysis[J].IEEE Trans. on Information Theory.1990, 36(5):961-1005[5]Mallat S G. A theory for multi-resolution signal decomposition: the wavelet representation[J].IEEE Trans. on Patt. Anal. and Mach. Intell.1989, 11(11):674-693[6]Falconer K J. Techniques in Fractal Geometry. London, UK: WlP, 1998: 7-15.[7]Chan W C Y, Tse C K. Studies of routes to chaos for current-programmed DC/DC converter. IEEE Trans. on Circ. Syst., 1996, 43(5): 789-795.[8]Wen W G, Wei X Y. Study on the route to chaos and stability of the current feedback controlled boost converter. .[J].proceeding of international conference on machine learning and cybernetics.2003, Xian:-[9]王利清, 魏學業, 溫偉剛. 電流模式Buck Boost電路從有序到混沌的分形研究. 北京交通大學學報, 2004, 28(5): 62-65. -
