InP/InGaAs(P)材料中的低溫開管Zn擴散
LOW TEMPERATURE OPEN TUBE Zn DIFFUSION IN InP/lnGaAs(P)
-
摘要: 為了在InP/InGaAs(P)材料中進行精確的選擇擴散,同時又要保證外延生長的多層異質結構不被破壞,提出了一種新的低溫開管Zn擴散方法。該法直至在T=500℃,t=5min的條件下,重復性仍很好。應用該法研究了低溫條件下Zn在InP,InGaAs(P)材料中的擴散行為。實驗首次發現,Zn在InGaAsP材料中的擴散速率與材料中P含量的平方成正比。
-
關鍵詞:
Abstract: A new method for accurate Zn diffusion in InP/InGaAs(P) at low temperature is put forward in order to keep the carrier profile in multilayers from redistribution. Several kinds of diffusion sources with different Zn contents are used in the experiment that shows good reprodu-cibility of the method. Using this method, the characteristics of low temperature Zn diffusion in InP, InGaAs and InGaAsP are studied, and it is found for the first time that the Zn diffusion, rate is proportional to the square of the phosphorus content in the materials. -
J. Shibata et al., Appl. Phys. Lett, 45(1984), 181.[2]R. E. Nabory et al., Integrated and Guided-Wave Optics, Tech. Dig. California (1982) p. Thc. 4.[3]張桂成等,電子科學學刊,5(1983)3, 95.[4]B. Tuck and A. Hooper, J. Phys. D: Appl. Phys., 8(1975), 1806.[5]N. Chand and P. A. Houston, J. Electron. Mater., 11(1982), 37.[6]Y. Matsumoto, Jpn. J. Appl. Phys., 22(1983), 1699.[7]P. N. Favennee et al., Electron. Lett., 16(1980), 832.[8] S. B. Phatak, IEEE Electron. Device Lett., EDL-3(1982), 132.[8]N. Chand and P. A. Houston, J. Electron. Mater., 14(1985), 9.[9]Y. R. Yuan et al., J. Appl. Phys., 54(1983), 6044.[10]T. Ambridge et al., Electron. Lett., 15(1979), 647. -
