圖像插值方法對互信息局部極值的影響分析
Study on Local Maxima Problem of Mutual Information in Different Resolution Images Registration
-
摘要: 多模態圖像配準中常使用互信息作為配準度量，互信息中的聯合概率密度函數一般是利用圖像灰度對的統計值來代替的，而圖像插值可能產生新的灰度對，造成互信息出現局部極值。該文利用一維信號從理論上分析了線性和最近鄰兩種插值方法對互信息的影響。理論分析表明，線性插值造成互信息局部極值的可能性較小，而最近鄰插值會使互信息出現周期性局部極值。試驗結果證實了該文的結論。分析結果對基于互信息的多模態圖像配準具有理論參考價值。
-
關鍵詞:
- 圖像配準; 互信息; 圖像插值
Abstract: Mutual information has been used as a similarity metric in medical image registration. The probabilities of mutual information may be estimated by normalization of the joint intensity histogram, which is obtained by binning the intensity pair of the overlapping parts of the reference image and the floating image. However, image interpolation would create new intensity pairs and may cause local maxima of mutual information. In this paper, local maxima of mutual information are analyzed using linear interpolation and near neighborhood interpolation for different resolution images. Analysis results show that mutual information contains less local maxima when linear interpolation is used, and contains local maxima when near neighborhood interpolation is used. Experiments show the validity of the results. All these results are benefit to multimodal medical image registration. -
Pluim J P W, Maintz J B A, Viergever Max A. Mutual-information-based registration of medical images: A Survey[J].IEEE Trans. on Medical Imaging.2003, 22(8):986-1004[2]Pluim J P W, Maintz J B A, Viergever M A. Image registration by maximization of combined mutual information and gradient information[J].IEEE Trans. on Medical Imaging.2000, 19(8):809-814[3]Viola P, Wells W M. III. Alignment by maximization of mutual information. the 5th International Conference on Computer Vision, Cambridge, MA , 1995: 16-23.Collignon A, Maes F, Delaere D, Vandermeulen D, et al.. Automated Multi-modality Image Registration Based on Information Theory: Information Processing in Medical Imaging, Dordrecht, Kluwer Academic, 1995: 263-274.[4]Ji Jim Xiuquan, Pan Hao, Liang Zhi-Pei. Further analysis of interpolation effects in mutual information-based image registration[J].IEEE Trans. on Medial Imaging.2003, 22(9):1131-1140[5]Pluim J P W, Maintz J B A, Viergever M A. Interpolation artifacts in mutual information based image registration[J].Computer Vision and Image Understanding.2000, 77(2):211-232[6]Tsao J. Interpolation artifacts in multimodality image registration based on maximization of mutual information[J].IEEE Trans. on Medical Imaging.2003, 22:854-864 -
