神經網絡高精度權值的模擬電路實現
ANALOG CIRCUIT IMPLEMENTATION OF NEURAL NETWORK WITH HIGH PRECISION WEIGHTS
-
摘要: 本文提出了一種電流模式4-bit可調權值模擬神經元電路,權值易存貯而且精度高。該電路可擴展為8-bit等多值分立權的神經元電路.文章扼要分析了神經元電路的工作原理,并用SPICE Ⅱ進行仿真,證明了這種電路的正確性。
-
關鍵詞:
- 神經網絡; 神經元; MOS集成電路
Abstract: A current-mode MOS neuron circuit with 4-bit programmable weights is presented using CMOS tetchnology. The weights of the neuron have high resolution and also can easily be digitally stored. The resolution can be extended into higher levels such as 8-bits, etc. by the design methodology presented in this paper. The operation principle of the neuron is discussed. Circuit simulation has been made by use of SPICE Ⅱ. The results give a good agreement for the design requirements. -
L. E. Atlas, Yoshitake Suzuki, IEEE Circuits and Devices Magazine, 5(1989)6, 20-24.[2]H. P. Graf, L. D. Jackel, IEEE Circuits and Devices Magazine, 5(1939)4, 44-49.[3]S.Y.Foo, L. R. Anderson, Yoshiyasu Takefuji, IEEE Circuits and Devices Magazine, 6(1990)4, 18-26.[4]M. Vereysen, P. G. A. Jespers, IEEE Micro, 9(198))6, 46-55.[5]A. G. Andreou et al., IEEE Trans. on NN, NN-2(1991)2, 205-213.[6]G. Moon, M. E[7]Zaghloul, R. W. Newcomb, IEEE Trans. on NN, NN-2(1992)3, 394-403. -
