雙端置數技術與高值CMOS觸發器設計
TWO-INPUTS PRESETTING TECHNIQUE AND DESIGN OF CMOS FLIP-FLOPS WITH A HIGH RADIX
-
摘要: 在分析以往高值觸發器困難的基礎上本文提出了雙端予置的邏輯設計方案。應用傳輸函數理論對四值CMOS觸發器進行了電路設計。結果表明,與存貯相同信息量的二個二值觸發器相比,它有較簡單的結構與較快的工作速度。Abstract: By analysing the difficulty of previous flip-flops with a high radix,this paper proposes a logic design scheme with two presetting inputs. The circuit of a quaternary CMOS flip-flop is designed by using the transmission function theory. The result shows that its structure is simpler and its processing speed is higher than that of two binary flip-flops which store the equal information.
-
Post E L. Amer. J. Matb., 1921,43: 163-196.[2]Hurst S L. IEEE Trans. on C, 1984,C-33: 1160-1179.[3]Etiemble D, Israel M.[J].Computer.1988,21:28-[4]Wu X(吳訓威).Int. J[J].Cir. Theor. Appl.1992,20:349-356[5]Wu X(吳訓威),Prosser F.,Int[J].J. Electron.1988, 65:891-905[6]吳訓威,陳偕雄,Prosser F.中國科學,A輯,1989,(5): 528-536.[7]Chen X(陳偕雄),Wu X(吳訓威).Int. J[J].Electron.1989,67:829-838[8]Vranesic Z G. IEEE Trans. on C, 1977,C-26:1181-1182.[9]Etiemble D. Israel M. On the realization of multiple-valued flip-flops. IEEE Proa. Int. Symp on MVL, Evanston: 1980,16-23.[10]吳訓威,，陳偕雄.中國科學(A輯),1985,(7): 643-654.[11]Wu X(吳訓威),Prosser F. Ternary CMOS sequential circuits. IEEE Proc. Int. Symp on MVL. Palms De Mallorca: 1999. 397-313. -
