星載行波管放大器雜波譜抑制的研究
Study of spurious spectrum suppression of spaceborne TWTA
-
摘要: 該文給出了星載行波管放大器(TWTA)雜波譜行為觀察的結果,分析了其形成機制,探討了雜波譜的抑制方法.研究表明只有從TWT設計和EPC電路設計兩方面采取措施,才有可能獲得高純頻譜。在此基礎上,將衛星用TWTA雜波譜振幅降低了10-15dB。
-
關鍵詞:
- 雜波譜; 星載TWTA; EPC; TWT
Abstract: This paper presents observed results of spurious spectrum of TWTA used for satel-lite. The rnechanism of spurious spectrum formation is analysed and the rnethods of its sup-pression are discussed. It is shown from the study that in order to obtain pure spectrum, the measures rnust be taken for both design of TWT and EPC circuit. Based on this study, the aruplitude of spurious spectrum of spaceborne TWTA has been reduced 10-15dB -
J.R.皮爾斯,行波管,北京,科學出版社,1961,附錄7.[2]陸鐘柞,行波管,上海,科學技術出版社,1962,第3.7節.[3]郵電五○六廠行波管編寫組,行波管,北京,人民郵電出版社,1979,第3.3節[4]K. Tsutaki, Y. Yuasa, Y. Morizumi, Numerical analysis and design for high-performance helix traveling-wave tubes, IEEE Trans. on Electron Devices, 1985, 32(9), 1842-1849.[5]AD 報告 AD-A181111.[6]任渠江,廖復疆,黃福金,螺線行波管一維大信號計算的研究報告,電子器件,1997,20(3),1-7.[7]葉慧貞,楊興洲,開關穩壓電源,北京,國防工業出版社,1994,第8.22節[8]C.L. Kory, Three dimensional simulation of helix traveling-wave tube cold-test characteristics using MAFIA, IEEE Trans. on Electron Devices, 1996, 43(8), 1317-1319.[9]C.L. Kory, J. A. Dayton, Accurate cold-test model of helical TWT slow-wave circuits, IEEE Trans. on Electron Devices. 1998, 45(4), 966-971. -
